46 489 GENERATOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
F123
Unsigned
16 bit integer
ALARM/TRIP STATUS
0Not Enabled
1Inactive
2Timing Out
3Active Trip
4 Latched Trip
F124
Unsigned
16 bit integer
PHASE ROTATION SELECTION
0 ----
1ABC
2ACB
F126
Unsigned
16 bit
DISABLED / ENABLED SELECTION
0 Disabled
1Enabled
Table CG–2: Data Formats (Sheet 5 of 14)
CODE TYPE DEFINITION
