489 GENERATOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 47
F127
Unsigned
16 bit integer
ANALOG OUTPUT PARAMETER SELECTION
0None
1IA Output Current
2IB Output Current
3 IC Output Current
4Average Output Current
5 Negative Sequence Current
6 Average Generator Load
7 Hottest Stator RTD
8 Hottest Bearing RTD
9Ambient RTD
10 RTD #1
11 RTD #2
12 RTD #3
13 RTD #4
14 RTD #5
15 RTD #6
16 RTD #7
17 RTD #8
18 RTD #9
19 RTD #10
20 RTD #11
21 RTD #12
22 AB Voltage
23 BC Voltage
24 CA Voltage
25 Average Voltage
26 Volts/Hertz
27 Frequency
28 Third Harmonic Neutral Voltage
29 Power Factor
30 Reactive Power (Mvar)
31 Real Power (MW)
32 Apparent Power (MVA)
33 Analog Input 1
34 Analog Input 2
35 Analog Input 3
36 Analog Input 4
37 Tachometer
38 Thermal Capacity Used
39 Current Demand
40 Mvar Demand
41 MW Demand
42 MVA Demand
Table CG–2: Data Formats (Sheet 6 of 14)
CODE TYPE DEFINITION
