CHAPTER 4: SETPOINTS TESTING
869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 4–405
5. Read the “Test Status” register. The values of 0, 1, 2 and 3 are for None, Testing, Passed
and Failed, respectively.
6. Read the “Tests Passed” count and “Tests Failed” count registers to determine the
number of tests that passed and failed respectively.
Table 4-41: Modbus Addresses
Data Item Data type Ethernet Port 4
Modbus Address
Ethernet Port 5
Modbus Address
Number of Tests Setpoint, 16 bit value 0XF212 0XF218
Test Start (Command) Setpoint, 16 bit enumeration 0XF213 0XF219
Test Status Actual Value, 16 bit enumeration 0XF214 0XF21A
Tests to Run Actual Value, 16 bits 0xF215 0XF21B
Tests Passed (Count) Actual Value, 16 bits 0xF216 0XF21C
Tests Failed (Count) Actual Value, 16 bits 0xF217 0XF21D
