CHAPTER 5: STATUS DEVICE STATUS
869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 5–17
Device Status
The general status of system components is displayed here.
Path: Status > Device Status
RUNNING, SAVING CID to FLASH
Range: YES, NO
Default: NO
CID HANDLING DONE
Range: YES, NO
Default: YES
SELF-TEST FAULT
Range: YES, NO
Default: NO
MAINTENANCE
Range: YES, NO
Default: NO
IN SERVICE
Range: YES, NO
Default: YES
PICKUP STATE
Range: YES, NO
Default: YES
BREAKER CONNECTED
Range: YES, NO
Default: YES
BREAKER CLOSED
Range: YES, NO
Default: NO
BREAKER TRIPPED
Range: YES, NO
Default: NO
ALARM
Range: YES, NO
Default: NO
TRIP
Range: YES, NO
Default: NO
ACTIVE GROUP
Range: SP Group 1-6 Active
Default: SP Group 1 Active
