Harmonics 1(Harmonics 4)
NOTE
NOTE:
The number of Harmonics supported is order code dependent.
All values relate to phase currents measured on the input card J1.
Path: Metering > Harmonics 1 - J1 Current
Phase A Total Harmonic Distortion (Phase A THD)
Range: 0.0 to 100.0 %
Phase B Total Harmonic Distortion (Phase B THD)
Range: 0.0 to 100.0 %
Phase C Total Harmonic Distortion (Phase C THD)
Range: 0.0 to 100.0 %
Phase A Second Harmonic (Phase A 2)
Range: 0.0 to 100.0 %
Phase B Second Harmonic (Phase B 2)
Range: 0.0 to 100.0 %
Phase C Second Harmonic (Phase C 2)
Range: 0.0 to 100.0 %
Phase A Third Harmonic (Phase A 3)
Range: 0.0 to 100.0 %
Phase B Third Harmonic (Phase B 3)
Range: 0.0 to 100.0 %
Phase C Third Harmonic (Phase C 3)
Range: 0.0 to 100.0 %
-
-
-
Phase A Twenty Fifth Harmonic (Phase A 25)
Range: 0.0 to 100.0 %
Phase B Twenty Fifth Harmonic (Phase B 25)
Range: 0.0 to 100.0 %
Phase C Twenty Fifth Harmonic (Phase C 25)
Range: 0.0 to 100.0 %
