CONNECTIONS
Connecting to a TV
Make sure that both the camera
and TV are turned o before con-
necting the AV cable.
By using the AV cable, you can view the
captured images on a TV. Follow the steps
below to connect the supplied AV cable to
a TV.
1. Connect one end of the AV cable to the
USB/AV OUT port on your camera.
2. Connect the plugs on the other end of
the cable to the audio and video input
ports on the TV.
3. Turn on the camera and the TV on.
