12 49-5000097 Rev. 4
Installation Instructions
6. INSTALL WINDOW LOCK
BRACKET AND FOAM TOP
WINDOW GASKET
8VH7\SH%6FUHZWRLQVWDOOWKHZLQGRZORFN
bracket on top of the bottom window.
A.
CAUTION
To prevent broken glass
or damage to windows,
on vinyl or other similarly
constructed windows,
attach the window locking
bracket to the window
side jamb with one Type B
screw.
B. Cut the foam top window gasket to the window
width.
C. Stuff the foam between the glass and the
window to prevent air and insects from getting
into the room.
NOTE: If the gasket supplied does not fit your
window, obtain appropriate material locally to
provide a proper installation seal.
Wood
Vinyl
