10
Care and cleaning of the air conditioner.
The front grille can be removed for more thorough cleaning and
to locate the model and serial numbers on the front of the base
pan.
To remove:
1. Pull the filter out.
2. Remove the two grille screws.
3. Pull the grille out from the bottom and lift up
from the tabs on the top of the case.
To replace:
Hook the tabs on the front grille even with the tabs on the case
and snap into place.
Replace the screws and filter.
Front Grille
Outdoor Coils
The coils on the outdoor side of the air conditioner should be
checked regularly.
If they are clogged with dirt or soot they may be professionally
steam cleaned, a service available through your GE service
outlet.
Grille and Case
Turn the air conditioner off and remove the plug from the
wall outlet before cleaning.
To clean, use water and a mild detergent.
Do not use bleach or abrasives.
Grille
Tab
On some models
On some models
Grille
Tab
