8
Installation Instructions
PARTS INCLUDED
(Appearance may vary)
Flexible Exhaust Hose Window Exhaust Adapter
Adjustable Window Slider
(2 for Normal Window Opening,
3 for Long Window Opening)
Window Locking BracketLarge Wood Screw (4)
Window Seal (2)Foam Seal
Window Slider Bracket (2)
Rain Deflector Assembly
Washer (4) Bolt (4) Nut (4)
Protective Screen
TOOLS YOU WILL NEED
Phillips head screwdriver
Pencil
Scissors or knife
PARTS YOU WILL NEED
• Wood filler strip and wood screws (for
double-hung windows, to match inner
width of window and inner height of
window stool)
Small Wood Screw (4)
Split-Ring Washer (4)
• You MUST use all supplied parts and use
proper installation procedures as described
in these instructions when installing this
air conditioner.
