3-4 ApexPro™ 2001989-351A
Installation and configuration
205A
Crimpers
The typical hex crimping tool is shown below. The recommended crimping tool part
numbers are the following.
For RG-6 plenum, use a HCT-659 crimper from CablePrep.
For RG-6 riser, use a CT611QS crimper from T&B.
For RG-11 riser and plenum, use a CT611QS crimper from T&B (recommended)
or HCT-211 crimper from CablePrep.
Before you crimp, check the dimensions for the specific type of coaxial cable and
connector.
215A
RG-6 plenum cable preparation
Required stripping dimensions for RG-6 plenum cabling are shown below.
