2-84 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 6335 Bank Phase Overvoltage 1 Curve Time
Multiplier
1 to 10 --- 0.01 F001 100
" 6336 Bank Phase Overvoltage 1 Stage 1A Pickup 0.8 to 2 pu 0.001 F001 1050
" 6337 Bank Phase Overvoltage 1 Stage 2A Pickup 0.8 to 2 pu 0.001 F001 1100
" 6338 Bank Phase Overvoltage 1 Stage 3A Pickup 0.8 to 2 pu 0.001 F001 1200
" 6339 Bank Phase Overvoltage 1 Stage 4A Pickup 0.8 to 2 pu 0.001 F001 1050
" 633A Bank Phase Overvoltage 1 Stage 1B Pickup 0.8 to 2 pu 0.001 F001 1050
" 633B Bank Phase Overvoltage 1 Stage 2B Pickup 0.8 to 2 pu 0.001 F001 1100
" 633C Bank Phase Overvoltage 1 Stage 3B Pickup 0.8 to 2 pu 0.001 F001 1200
" 633D Bank Phase Overvoltage 1 Stage 4B Pickup 0.8 to 2 pu 0.001 F001 1050
" 633E Bank Phase Overvoltage 1 Stage 1C Pickup 0.8 to 2 pu 0.001 F001 1050
" 633F Bank Phase Overvoltage 1 Stage 2C Pickup 0.8 to 2 pu 0.001 F001 1100
" 6340 Bank Phase Overvoltage 1 Stage 3C Pickup 0.8 to 2 pu 0.001 F001 1200
" 6341 Bank Phase Overvoltage 1 Stage 4C Pickup 0.8 to 2 pu 0.001 F001 1050
" 6342 Bank Phase Overvoltage 1 Stage 1 Pickup
Delay
0 to 600 s 0.01 F001 6000
" 6343 Bank Phase Overvoltage 1 Stage 2 Pickup
Delay
0 to 600 s 0.01 F001 1000
" 6344 Bank Phase Overvoltage 1 Stage 3 Pickup
Delay
0 to 600 s 0.01 F001 200
" 6345 Bank Phase Overvoltage 1 Dropout Delay 0 to 600 s 0.01 F001 25
" 6346 Bank Phase Overvoltage 1 Block 0 to 4294967295 --- 1 F300 0
" 6348 Bank Phase Overvoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 6349 Bank Phase Overvoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 634A ...Repeated for Bank Phase Overvoltage 2
" 6364 ...Repeated for Bank Phase Overvoltage 3
Capacitor Bank Overvoltage Actuals (Read Only) (3 Modules)
C70 6390 Bank Overvoltage 1 Phase A Operate
Voltage
0 to 65.535 pu 0.001 F001 0
" 6391 Bank Overvoltage 1 Phase B Operate
Voltage
0 to 65.535 pu 0.001 F001 0
" 6392 Bank Overvoltage 1 Phase C Operate
Voltage
0 to 65.535 pu 0.001 F001 0
" 6393 ...Repeated for Bank Overvoltage 2
" 6396 ...Repeated for Bank Overvoltage 3
Negative Sequence Instantaneous Overcurrent (Read/Write Grouped Setting) (2 or 3 Modules)
C70, D30, D60,
F35, F60, L30,
L60, L90, T60
63C0 Negative Sequence Instantaneous OC 1
Function
0 to 1 --- 1 F102 0 (Disabled)
" 63C1 Negative Sequence Instantaneous OC 1
Signal Source
0 to 5 --- 1 F167 0 (SRC 1)
" 63C2 Negative Sequence Instantaneous
Overcurrent 1 Pickup
0.02 to 30 pu 0.001 F001 1000
" 63C3 Negative Sequence Instantaneous
Overcurrent 1 Delay
0 to 600 s 0.01 F001 0
" 63C4 Negative Sequence Instantaneous OC 1
Reset Delay
0 to 600 s 0.01 F001 0
" 63C5 Negative Sequence Instantaneous
Overcurrent 1 Block
0 to 4294967295 --- 1 F300 0
" 63C7 Negative Sequence Instantaneous
Overcurrent 1 Target
0 to 2 --- 1 F109 0 (Self-reset)
Products Address Register name Range Units Step Format Default
