2-96 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 6888 Autoreclose Transfer 2 to 1 0 to 1 --- 1 F126 0 (No)
" 6889 Autoreclose Breaker 1 Fail Option 0 to 1 --- 1 F081 0 (Continue)
" 688A Autoreclose Breaker 2 Fail Option 0 to 1 --- 1 F081 0 (Continue)
" 688B Autoreclose 1P Dead Time 0 to 655.35 s 0.01 F001 100
" 688C Autoreclose Breaker Sequence 0 to 4 --- 1 F082 3 (1 - 2)
" 688D Autoreclose Transfer Time 0 to 655.35 s 0.01 F001 400
" 688E Autoreclose Event 0 to 1 --- 1 F102 0 (Disabled)
" 688F Autoreclose 3P Dead Time 3 0 to 655.35 s 0.01 F001 200
" 6890 Autoreclose 3P Dead Time 4 0 to 655.35 s 0.01 F001 400
" 6891 Autoreclose Bus Fault Initiate 0 to 4294967295 --- 1 F300 0
" 6893 Autoreclose Initiate Mode 0 to 1 --- 1 F610 0 (Protection
AND CB)
" 6894 Autoreclose Mode Aut 0 to 3 --- 1 F622 0 (Mode 1 (1
& 3 Pole))
" 6895 Autoreclose Mode 1 Activation 0 to 4294967295 --- 1 F300 0
" 6897 Autoreclose Mode 2 Activation 0 to 4294967295 --- 1 F300 0
" 6899 Autoreclose Mode 3 Activation 0 to 4294967295 --- 1 F300 0
" 689B Autoreclose Mode 4 Activation 0 to 4294967295 --- 1 F300 0
Pilot Directional Comparison Unblocking (DCUB) Scheme (Read/Write Setting)
D60, L90 68A0 Directional Comparison Unblocking
Scheme Function
0 to 1 --- 1 F102 0 (Disabled)
" 68A1 Directional Comparison Unblocking Block 0 to 4294967295 --- 1 F300 0
" 68A3 Directional Comparison Unblocking
Permissive Echo
0 to 2 --- 1 F199 0 (Disabled)
" 68A4 Directional Comparison Unblocking Echo
Condition
0 to 4294967295 --- 1 F300 0
" 68A6 DCUB Ground Directional Overcurrent
Forward
0 to 4294967295 --- 1 F300 0
" 68A8 DCUB Ground Directional Overcurrent
Reverse
0 to 4294967295 --- 1 F300 0
" 68AA DCUB Transmit Block Pickup Delay 0 to 65.535 s 0.001 F001 20
" 68AB DCUB Transmit Block Reset Delay 0 to 65.535 s 0.001 F001 90
" 68AC Directional Comparison Unblocking Echo
Duration
0 to 65.535 s 0.001 F001 100
" 68AD Directional Comparison Unblocking Echo
Lockout
0 to 65.535 s 0.001 F001 250
" 68AE DCUB Line End Open Pickup Delay 0 to 65.535 s 0.001 F001 50
" 68AF DCUB Loss-of-Guard (Log) Pickup Delay 0 to 65.535 s 0.001 F001 8
" 68B0 DCUB Guard Healthy Reset Delay 0 to 65.535 s 0.001 F001 15
" 68B1 DCUB Loss-of-Guard Trip Window 0 to 65.535 s 0.001 F001 150
" 68B2 Directional Comparison Unblocking Seal-In
Delay
0 to 65.535 s 0.001 F001 10
" 68B3 Directional Comparison Unblocking
Communication Bits
0 to 2 --- 1 F198 0 (1 bit)
" 68B4 Directional Comparison Unblocking Rx1 0 to 4294967295 --- 1 F300 0
" 68B6 Directional Comparison Unblocking Log1 0 to 4294967295 --- 1 F300 0
" 68B8 Directional Comparison Unblocking Rx2 0 to 4294967295 --- 1 F300 0
" 68BA Directional Comparison Unblocking Log2 0 to 4294967295 --- 1 F300 0
" 68BC Directional Comparison Unblocking Rx3 0 to 4294967295 --- 1 F300 0
" 68BE Directional Comparison Unblocking Log3 0 to 4294967295 --- 1 F300 0
Products Address Register name Range Units Step Format Default
