GE b30 Communications Guide

2-98 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 6958 Reserved (8 items) --- --- --- F001 0
Motor Learned Data (Read/Write Setting)
M60 6960 Motor Learned Data Starts to Learn 1 to 5 --- 1 F001 1
" 6961 Motor Learned Data Calculation Period 1 to 90 minutes 1 F001 15
" 6962 Reserved --- --- --- F001 0
Motor Learned Data Actual Values (Read Only)
M60 6963 Motor Learned Data Records Number 0 to 250 --- 1 F001 0
" 6964 Motor Learned Data Last Cleared Date 0 to 4294967295 --- --- F050 0
" 6966 Motor Learned Data Last Acceleration
Time
0 to 655.35 s 0.01 F001 0
" 6967 Motor Learned Data Last Starting Current 0 to 40 × FLA 0.01 F001 0
" 6968 Motor Learned Data Last Thermal Capacity
Used
0 to 65535 % 1 F001 0
" 6969 Motor Learned Data Last Average Motor
Load
0 to 40 × FLA 0.01 F001 0
" 696A Motor Learned Data Last Run Time After
Start
0 to 4294967295 hr 1 F050 0
" 696C Reserved --- --- --- F001 0
RTD Inputs (Read/Write Setting) (48 Modules)
All except B90 6970 RTD Input 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 6971 RTD Input 1 ID --- --- --- F205 “RTD Ip 1“
" 6977 RTD Input 1 Type 0 to 3 --- 1 F174 0 (100 ohm
Platinum)
" 6978 RTD Input 1 Application 0 to 5 --- 1 F550 0 (None)
" 6979 RTD Input 1 Alarm Temperature 1 to 249 °C 1 F001 130
" 697A RTD Input 1 Alarm Pickup Delay 0 to 600 s 0.01 F001 0
" 697B RTD Input 1 Trip Temperature 1 to 249 °C 1 F001 130
" 697C RTD Input 1 Trip Pickup Delay 0 to 600 s 0.01 F001 0
" 697D RTD Input 1 Trip Reset Delay 0 to 600 s 0.01 F001 0
" 697E RTD Input 1 Trip Voting 0 to 48 --- 1 F551 0
" 697F RTD Input 1 Open 0 to 2 --- 1 F552 0 (None)
" 6980 RTD Input 1 Block 0 to 4294967295 --- 1 F300 0
" 6982 RTD Input 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 6983 RTD Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 6984 ...Repeated for RTD Input 2
" 6998 ...Repeated for RTD Input 3
" 69AC ...Repeated for RTD Input 4
" 69C0 ...Repeated for RTD Input 5
" 69D4 ...Repeated for RTD Input 6
" 69E8 ...Repeated for RTD Input 7
" 69FC ...Repeated for RTD Input 8
" 6A10 ...Repeated for RTD Input 9
" 6A24 ...Repeated for RTD Input 10
" 6A38 ...Repeated for RTD Input 11
" 6A4C ...Repeated for RTD Input 12
" 6A60 ...Repeated for RTD Input 13
" 6A74 ...Repeated for RTD Input 14
" 6A88 ...Repeated for RTD Input 15
Products Address Register name Range Units Step Format Default
