2-102 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 6ECC ...Repeated for Isolator 45
" 6ED8 ...Repeated for Isolator 46
" 6EE4 ...Repeated for Isolator 47
6EF0 ...Repeated for Isolator 48
Terminal Current (Read Only) (24 Modules)
B90 6F00 Terminal Current 1 Magnitude 0 to 999999.999 A 0.001 F060 0
" 6F02 Terminal Current 1 Angle -359.9 to 0 degrees 0.1 F002 0
" 6F03 ...Repeated for Terminal Current 2
" 6F06 ...Repeated for Terminal Current 3
" 6F09 ...Repeated for Terminal Current 4
" 6F0C ...Repeated for Terminal Current 5
" 6F0F ...Repeated for Terminal Current 6
" 6F12 ...Repeated for Terminal Current 7
" 6F15 ...Repeated for Terminal Current 8
" 6F18 ...Repeated for Terminal Current 9
" 6F1B ...Repeated for Terminal Current 10
" 6F1E ...Repeated for Terminal Current 11
" 6F21 ...Repeated for Terminal Current 12
" 6F24 ...Repeated for Terminal Current 13
" 6F27 ...Repeated for Terminal Current 14
" 6F2A ...Repeated for Terminal Current 15
" 6F2D ...Repeated for Terminal Current 16
" 6F30 ...Repeated for Terminal Current 17
" 6F33 ...Repeated for Terminal Current 18
" 6F36 ...Repeated for Terminal Current 19
" 6F39 ...Repeated for Terminal Current 20
" 6F3C ...Repeated for Terminal Current 21
" 6F3F ...Repeated for Terminal Current 22
" 6F42 ...Repeated for Terminal Current 23
" 6F45 ...Repeated for Terminal Current 24
Terminal Voltage (Read Only) (12 Modules)
B90 6F48 Terminal Voltage 1 Magnitude 0 to 999999.999 V 0.001 F060 0
" 6F4A Terminal Voltage 1 Angle -359.9 to 0 degrees 0.1 F002 0
" 6F4B ...Repeated for Terminal Voltage 2
" 6F4E ...Repeated for Terminal Voltage 3
" 6F51 ...Repeated for Terminal Voltage 4
" 6F54 ...Repeated for Terminal Voltage 5
" 6F57 ...Repeated for Terminal Voltage 6
" 6F5A ...Repeated for Terminal Voltage 7
" 6F5D ...Repeated for Terminal Voltage 8
" 6F60 ...Repeated for Terminal Voltage 9
" 6F63 ...Repeated for Terminal Voltage 10
" 6F66 ...Repeated for Terminal Voltage 11
" 6F69 ...Repeated for Terminal Voltage 12
CT Terminal Settings (Read/Write Setting) (24 Modules)
B90 6F6C Terminal Current 1 Primary 1 to 65000 A 1 F001 1
" 6F6D Terminal Current 1 Secondary 0 to 1 --- 1 F123 0 (1 A)
