CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-103
2
" 6F6E ...Repeated for Terminal Current 2
" 6F70 ...Repeated for Terminal Current 3
" 6F72 ...Repeated for Terminal Current 4
" 6F74 ...Repeated for Terminal Current 5
" 6F76 ...Repeated for Terminal Current 6
" 6F78 ...Repeated for Terminal Current 7
" 6F7A ...Repeated for Terminal Current 8
" 6F7C ...Repeated for Terminal Current 9
" 6F7E ...Repeated for Terminal Current 10
" 6F80 ...Repeated for Terminal Current 11
" 6F82 ...Repeated for Terminal Current 12
" 6F84 ...Repeated for Terminal Current 13
" 6F86 ...Repeated for Terminal Current 14
" 6F88 ...Repeated for Terminal Current 15
" 6F8A ...Repeated for Terminal Current 16
" 6F8C ...Repeated for Terminal Current 17
" 6F8E ...Repeated for Terminal Current 18
" 6F90 ...Repeated for Terminal Current 19
" 6F92 ...Repeated for Terminal Current 20
" 6F94 ...Repeated for Terminal Current 21
" 6F96 ...Repeated for Terminal Current 22
" 6F98 ...Repeated for Terminal Current 23
" 6F9A ...Repeated for Terminal Current 24
VT Terminal Settings (Read/Write Setting) (12 Modules)
B90 6F9C Terminal Voltage 1 Ratio 1 to 24000 :1 0.01 F060 1
" 6F9E Terminal Voltage 1 Secondary 50 to 240 V 0.1 F001 664
" 6F9F ...Repeated for Terminal Voltage 2
" 6FA2 ...Repeated for Terminal Voltage 3
" 6FA5 ...Repeated for Terminal Voltage 4
" 6FA8 ...Repeated for Terminal Voltage 5
" 6FAB ...Repeated for Terminal Voltage 6
" 6FAE ...Repeated for Terminal Voltage 7
" 6FB1 ...Repeated for Terminal Voltage 8
" 6FB4 ...Repeated for Terminal Voltage 9
" 6FB7 ...Repeated for Terminal Voltage 10
" 6FBA ...Repeated for Terminal Voltage 11
" 6FBD ...Repeated for Terminal Voltage 12
B90 Function (Read/Write Setting)
B90 6FC0 B90 Function 0 to 1 --- 1 F250 1
(Protection)
Terminal Frequency (Read Only)
B90 6FD0 Terminal Frequency 2 to 90 Hz 0.01 F001 0
" 6FD1 Terminal Tracking Frequency 2 to 90 Hz 0.01 F001 0
Breaker Failure Current Supervision (Read/Write Grouped Setting) (24 Modules)
B90 7000 Breaker Failure 1 Current Supervision
Function
0 to 1 --- 1 F102 0 (Disabled)
" 7001 Breaker Failure 1 Current Supervision CT 0 to 23 --- 1 F400 0
Products Address Register name Range Units Step Format Default
