2-104 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 7002 Breaker Failure 1 Current Supervision Amp
Supv Pickup
0.02 to 30 pu 0.001 F001 1050
" 7003 Breaker Failure 1 Current Supervision Amp
Hiset Pickup
0.02 to 30 pu 0.001 F001 1050
" 7004 Breaker Failure 1 Current Supervision Amp
Loset Pickup
0.02 to 30 pu 0.001 F001 1050
" 7005 Reserved (4 items) 0 to 65535 --- 1 F001 0
" 7009 ...Repeated for Breaker Failure 2
" 7012 ...Repeated for Breaker Failure 3
" 701B ...Repeated for Breaker Failure 4
" 7024 ...Repeated for Breaker Failure 5
" 702D ...Repeated for Breaker Failure 6
" 7036 ...Repeated for Breaker Failure 7
" 703F ...Repeated for Breaker Failure 8
" 7048 ...Repeated for Breaker Failure 9
" 7051 ...Repeated for Breaker Failure 10
" 705A ...Repeated for Breaker Failure 11
" 7063 ...Repeated for Breaker Failure 12
" 706C ...Repeated for Breaker Failure 13
" 7075 ...Repeated for Breaker Failure 14
" 707E ...Repeated for Breaker Failure 15
" 7087 ...Repeated for Breaker Failure 16
" 7090 ...Repeated for Breaker Failure 17
" 7099 ...Repeated for Breaker Failure 18
" 70A2 ...Repeated for Breaker Failure 19
" 70AB ...Repeated for Breaker Failure 20
" 70B4 ...Repeated for Breaker Failure 21
" 70BD ...Repeated for Breaker Failure 22
" 70C6 ...Repeated for Breaker Failure 23
" 70CF ...Repeated for Breaker Failure 24
Phase Undervoltage (Read/Write Grouped Setting) (3 Modules)
All except B90,
C30, T35
7000 Phase Undervoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 7001 Phase Undervoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
" 7002 Phase Undervoltage 1 Pickup 0.004 to 3 pu 0.001 F001 1000
" 7003 Phase Undervoltage 1 Curve 0 to 1 --- 1 F111 0 (Definite
Time)
" 7004 Phase Undervoltage 1 Delay 0 to 600 s 0.01 F001 100
" 7005 Phase Undervoltage 1 Minimum Voltage 0 to 3 pu 0.001 F001 100
" 7006 Phase Undervoltage 1 Block 0 to 4294967295 --- 1 F300 0
" 7008 Phase Undervoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 7009 Phase Undervoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 700A Phase Undervoltage 1 Measurement Mode 0 to 1 --- 1 F186 0 (Phase to
Ground)
" 700B Reserved (6 items) 0 to 1 --- 1 F001 0
" 7013 ...Repeated for Phase Undervoltage 2
" 7022 ...Repeated for Phase Undervoltage 3
Products Address Register name Range Units Step Format Default
