2-112 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 7632 ...Repeated for Instantaneous Overcurrent
6
" 763C ...Repeated for Instantaneous Overcurrent
7
" 7646 ...Repeated for Instantaneous Overcurrent
8
" 7650 ...Repeated for Instantaneous Overcurrent
9
" 765A ...Repeated for Instantaneous Overcurrent
10
" 7664 ...Repeated for Instantaneous Overcurrent
11
" 766E ...Repeated for Instantaneous Overcurrent
12
" 7678 ...Repeated for Instantaneous Overcurrent
13
" 7682 ...Repeated for Instantaneous Overcurrent
14
" 768C ...Repeated for Instantaneous Overcurrent
15
" 7696 ...Repeated for Instantaneous Overcurrent
16
" 76A0 ...Repeated for Instantaneous Overcurrent
17
" 76AA ...Repeated for Instantaneous Overcurrent
18
" 76B4 ...Repeated for Instantaneous Overcurrent
19
" 76BE ...Repeated for Instantaneous Overcurrent
20
" 76C8 ...Repeated for Instantaneous Overcurrent
21
" 76D2 ...Repeated for Instantaneous Overcurrent
22
" 76DC ...Repeated for Instantaneous Overcurrent
23
" 76E6 ...Repeated for Instantaneous Overcurrent
24
Time Overcurrent (Read/Write Grouped Setting) (24 Modules)
B90 7700 Time Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 7701 Time Overcurrent 1 CT Setting 0 to 23 --- 1 F400 0
" 7702 Time Overcurrent 1 Pickup 0.02 to 30 pu 0.001 F001 1200
" 7703 Time Overcurrent 1 Curve 0 to 16 --- 1 F103 0 (IEEE Mod
Inv)
" 7704 Time Overcurrent 1 Multiplier 0 to 600 --- 0.01 F001 100
" 7705 Time Overcurrent 1 Reset 0 to 1 --- 1 F104 0
(Instantaneo
us)
" 7706 Time Overcurrent 1 Block 0 to 4294967295 --- 1 F300 0
" 7708 Time Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 7709 Time Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 770A Reserved (2 items) 0 to 65535 --- 1 F001 0
" 770C ...Repeated for Time Overcurrent 2
" 7718 ...Repeated for Time Overcurrent 3
Products Address Register name Range Units Step Format Default
