CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-119
2
" 7B81 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 7B82 User Programmable Pushbutton 1 LED
Operand
0 to 4294967295 --- 1 F300 0
" 7B84 User Programmable Pushbutton 1
Autoreset Delay
0.2 to 600 s 0.1 F001 10
" 7B85 User Programmable Pushbutton 1
Autoreset Function
0 to 1 --- 1 F102 0 (Disabled)
" 7B86 User Programmable Pushbutton 1 Local
Lock Operand
0 to 4294967295 --- 1 F300 0
" 7B88 User Programmable Pushbutton 1
Message Priority
0 to 2 --- 1 F220 0 (Disabled)
" 7B89 User Programmable Pushbutton 1 Remote
Lock Operand
0 to 4294967295 --- 1 F300 0
" 7B8B User Programmable Pushbutton 1 Reset
Operand
0 to 4294967295 --- 1 F300 0
" 7B8D User Programmable Pushbutton 1 Set
Operand
0 to 4294967295 --- 1 F300 0
" 7B8F User Programmable Pushbutton 1 Hold 0 to 10 s 0.1 F001 1
" 7B90 ...Repeated for User Programmable
Pushbutton 2
" 7BC0 ...Repeated for User Programmable
Pushbutton 3
" 7BF0 ...Repeated for User Programmable
Pushbutton 4
" 7C20 ...Repeated for User Programmable
Pushbutton 5
" 7C50 ...Repeated for User Programmable
Pushbutton 6
" 7C80 ...Repeated for User Programmable
Pushbutton 7
" 7CB0 ...Repeated for User Programmable
Pushbutton 8
" 7CE0 ...Repeated for User Programmable
Pushbutton 9
" 7D10 ...Repeated for User Programmable
Pushbutton 10
" 7D40 ...Repeated for User Programmable
Pushbutton 11
" 7D70 ...Repeated for User Programmable
Pushbutton 12
" 7DA0 ...Repeated for User Programmable
Pushbutton 13
" 7DD0 ...Repeated for User Programmable
Pushbutton 14
" 7E00 ...Repeated for User Programmable
Pushbutton 15
" 7E30 ...Repeated for User Programmable
Pushbutton 16
High Impedance Fault Detection (Hi-Z) Settings (Read/Write Setting)
F60 7E60 Hi-Z Function 0 to 1 --- 1 F102 0 (Disabled)
" 7E61 Hi-Z Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
" 7E62 Hi-Z Arcing Sensitivity 1 to 10 --- 1 F001 5
" 7E63 Hi-Z Phase Event Count 10 to 250 --- 1 F001 30
" 7E64 Hi-Z Ground Event Count 10 to 500 --- 1 F001 30
