GE b30 Communications Guide

2-142 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 9FFC ...Repeated for Direct Input 256
Automatic Voltage Regulator Settings (Read/Write) (3 Modules)
C70 9C90 Automatic Voltage Regulator 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 9C91 Automatic Voltage Regulator 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" 9C92 Automatic Voltage Regulator 1 Minimum
Voltage
0.5 to 1.5 pu 0.001 F001 500
" 9C93 Automatic Voltage Regulator 1 Control
Mode
0 to 1 --- 1 F536 0 (Voltage)
" 9C94 Automatic Voltage Regulator 1 Voltage
Operating Signal
0 to 8 --- 1 F535 4 (V1)
" 9C95 Automatic Voltage Regulator 1 Voltage
Level to Close
0.75 to 1.5 pu 0.001 F001 950
" 9C96 Automatic Voltage Regulator 1 Voltage
Level to Open
0.75 to 1.5 pu 0.001 F001 1050
" 9C97 AVR 1 Voltage Drop Compensation
Impedance
0 to 250 ohms 0.01 F001 0
" 9C98 AVR 1 Voltage Drop Compensation RCA 30 to 90 ° 1 F001 75
" 9C99 Automatic Voltage Regulator 1 VAR Level to
Close
–1.5 to 1.5 pu 0.001 F002 950
" 9C9A Automatic Voltage Regulator 1 VAR Level to
Open
–1.5 to 1.5 pu 0.001 F002 1050
" 9C9B Automatic Voltage Regulator 1 Power
Factor Limit
0.5 to 1 --- 0.01 F001 100
" 9C9C Automatic Voltage Regulator 1 VAR Open
Mode
0 to 1 --- 1 F537 1 (Minimize
No. of Ops.)
" 9C9D Automatic Voltage Regulator 1 Delay
Before Close
0 to 65.535 s 0.001 F001 1000
" 9C9E Automatic Voltage Regulator 1 Delay
Before Open
0 to 65.535 s 0.001 F001 1000
" 9C9F Automatic Voltage Regulator 1 Block 0 to 4294967295 --- 1 F300 0
" 9CA1 Automatic Voltage Regulator 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 9CA2 Automatic Voltage Regulator 1 Target 0 to 2 --- 1 F109 0 (Self-Reset)
" 9CA3 Automatic Voltage Regulator 1 Reserved 0 to 0.001 --- 0.001 F001 0
" 9CA4 ...Repeated for Automatic Voltage
Regulator 2
" 9CB8 ...Repeated for Automatic Voltage
Regulator 3
Neutral Current Unbalance Settings (Read/Write Grouped Setting) (3 Modules)
C70 9CE0 Neutral Current Unbalance 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 9CE1 Neutral Current Unbalance 1 Bank Source 0 to 5 --- 1 F167 0 (SRC 1)
" 9CE2 Neutral Current Unbalance 1 k Magnitude 0 to 0.15 --- 0.000
1
F001 0
" 9CE3 Neutral Current Unbalance 1 k Angle 0 to 359 ° 1 F001 0
" 9CE4 Neutral Current Unbalance 1 Stage 1
Pickup
0 to 5 pu 0.001 F001 20
" 9CE5 Neutral Current Unbalance 1 Stage 1 Slope 0 to 10 % 0.1 F001 20
" 9CE6 Neutral Current Unbalance 1 Stage 2
Pickup
0 to 5 pu 0.001 F001 30
" 9CE7 Neutral Current Unbalance 1 Stage 2 Slope 0 to 10 % 0.1 F001 20
" 9CE8 Neutral Current Unbalance 1 Stage 3
Pickup
0 to 5 pu 0.001 F001 40
" 9CE9 Neutral Current Unbalance 1 Stage 3 Slope 0 to 10 % 0.1 F001 20
Products Address Register name Range Units Step Format Default
