CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-143
2
" 9CEA Neutral Current Unbalance 1 Stage 4
Pickup
0 to 5 pu 0.001 F001 50
" 9CEB Neutral Current Unbalance 1 Stage 4 Slope 0 to 10 % 0.1 F001 50
" 9CEC Neutral Current Unbalance 1 Stage 1
Pickup Delay
0 to 600 s 0.01 F001 3000
" 9CED Neutral Current Unbalance 1 Stage 2
Pickup Delay
0 to 600 s 0.01 F001 1000
" 9CEE Neutral Current Unbalance 1 Stage 3
Pickup Delay
0 to 600 s 0.01 F001 100
" 9CEF Neutral Current Unbalance 1 Stage 4
Pickup Delay
0 to 600 s 0.01 F001 20
" 9CF0 Neutral Current Unbalance 1 Dropout
Delay
0 to 600 s 0.01 F001 25
" 9CF1 Neutral Current Unbalance 1 Stage 1 Block 0 to 4294967295 --- 1 F300 0
" 9CF3 Neutral Current Unbalance 1 Stage 2 Block 0 to 4294967295 --- 1 F300 0
" 9CF5 Neutral Current Unbalance 1 Stage 3 Block 0 to 4294967295 --- 1 F300 0
" 9CF7 Neutral Current Unbalance 1 Stage 4 Block 0 to 4294967295 --- 1 F300 0
" 9CF9 Neutral Current Unbalance 1 Target 0 to 2 --- 1 F109 0 (Self-Reset)
" 9CFA Neutral Current Unbalance 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 9CFB ...Repeated for Neutral Current Unbalance
2
" 9D16 ...Repeated for Neutral Current Unbalance
3
Neutral Voltage Unbalance Settings (Read/Write Grouped Setting) (3 Modules)
C70 9D50 Neutral Voltage Unbalance 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 9D51 Neutral Voltage Unbalance 1 Neutral-Point
Source
0 to 5 --- 1 F167 0 (SRC 1)
" 9D52 Neutral Voltage Unbalance 1 Bus Source 0 to 5 --- 1 F167 0 (SRC 1)
" 9D53 Neutral Voltage Unbalance 1 Bus 3V0 0 to 1 --- 1 F241 0
(Calculated)
" 9D54 Neutral Voltage Unbalance 1 Ground 0 to 1 --- 1 F255 0 (VT
(ungrnd))
" 9D55 Neutral Voltage Unbalance 1 AB Ratio 0.75 to 1.25 --- 0.000
1
F001 10000
" 9D56 Neutral Voltage Unbalance 1 AC Ratio 0.75 to 1.25 --- 0.000
1
F001 10000
" 9D57 Neutral Voltage Unbalance 1 Stage 1
Pickup
0.001 to 1 pu 0.001 F001 10
" 9D58 Neutral Voltage Unbalance 1 Stage 1 Slope 0 to 10 % 0.1 F001 0
" 9D59 Neutral Voltage Unbalance 1 Stage 2
Pickup
0.001 to 1 pu 0.001 F001 20
" 9D5A Neutral Voltage Unbalance 1 Stage 2 Slope 0 to 10 % 0.1 F001 0
" 9D5B Neutral Voltage Unbalance 1 Stage 3
Pickup
0.001 to 1 pu 0.001 F001 20
" 9D5C Neutral Voltage Unbalance 1 Stage 3 Slope 0 to 10 % 0.1 F001 50
" 9D5D Neutral Voltage Unbalance 1 Stage 4
Pickup
0.001 to 1 pu 0.001 F001 30
" 9D5E Neutral Voltage Unbalance 1 Stage 4 Slope 0 to 10 % 0.1 F001 50
" 9D5F Neutral Voltage Unbalance 1 Stage 1
Pickup Delay
0 to 600 s 0.01 F001 3000
" 9D60 Neutral Voltage Unbalance 1 Stage 2
Pickup Delay
0 to 600 s 0.01 F001 1000
Products Address Register name Range Units Step Format Default
