CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-145
2
" 9DD3 Phase Current Unbalance 1 Stage 2 Pickup
Delay
0 to 600 s 0.01 F001 1000
" 9DD4 Phase Current Unbalance 1 Stage 3 Pickup
Delay
0 to 600 s 0.01 F001 100
" 9DD5 Phase Current Unbalance 1 Stage 4 Pickup
Delay
0 to 600 s 0.01 F001 20
" 9DD6 Phase Current Unbalance 1 Dropout Delay 0 to 600 s 0.01 F001 25
" 9DD7 Phase Current Unbalance 1 Stage 1 Block 0 to 4294967295 --- 1 F300 0
" 9DD9 Phase Current Unbalance 1 Stage 2 Block 0 to 4294967295 --- 1 F300 0
" 9DDB Phase Current Unbalance 1 Stage 3 Block 0 to 4294967295 --- 1 F300 0
" 9DDD Phase Current Unbalance 1 Stage 4 Block 0 to 4294967295 --- 1 F300 0
" 9DDF Phase Current Unbalance 1 Target 0 to 2 --- 1 F109 0 (Self-Reset)
" 9DE0 Phase Current Unbalance 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 9DE1 ...Repeated for Phase Current Unbalance 2
" 9E02 ...Repeated for Phase Current Unbalance 3
Voltage Differential Settings (Read/Write Grouped Setting) (3 Modules)
C70 9E40 Voltage Differential 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 9E41 Voltage Differential 1 Bus Source 0 to 5 --- 1 F167 0 (SRC 1)
" 9E42 Voltage Differential 1 Tap Source 0 to 5 --- 1 F167 0 (SRC 1)
" 9E43 Voltage Differential 1 Bank Ground 0 to 1 --- 1 F091 0 (Grounded)
" 9E44 Voltage Differential 1 Match Factor A 0.5 to 2000 --- 0.000
1
F003 20000
" 9E46 Voltage Differential 1 Match Factor B 0.5 to 2000 --- 0.000
1
F003 20000
" 9E48 Voltage Differential 1 Match Factor C 0.5 to 2000 --- 0.000
1
F003 20000
" 9E4A Voltage Differential 1 Stage 1A Pickup 0.001 to 1 pu 0.001 F001 10
" 9E4B Voltage Differential 1 Stage 2A Pickup 0.001 to 1 pu 0.001 F001 20
" 9E4C Voltage Differential 1 Stage 3A Pickup 0.001 to 1 pu 0.001 F001 30
" 9E4D Voltage Differential 1 Stage 4A Pickup 0.001 to 1 pu 0.001 F001 40
" 9E4E Voltage Differential 1 Stage 1B Pickup 0.001 to 1 pu 0.001 F001 10
" 9E4F Voltage Differential 1 Stage 2B Pickup 0.001 to 1 pu 0.001 F001 20
" 9E50 Voltage Differential 1 Stage 3B Pickup 0.001 to 1 pu 0.001 F001 30
" 9E51 Voltage Differential 1 Stage 4B Pickup 0.001 to 1 pu 0.001 F001 40
" 9E52 Voltage Differential 1 Stage 1C Pickup 0.001 to 1 pu 0.001 F001 10
" 9E53 Voltage Differential 1 Stage 2C Pickup 0.001 to 1 pu 0.001 F001 20
" 9E54 Voltage Differential 1 Stage 3C Pickup 0.001 to 1 pu 0.001 F001 30
" 9E55 Voltage Differential 1 Stage 4C Pickup 0.001 to 1 pu 0.001 F001 40
" 9E56 Voltage Differential 1 Stage 1 Pickup Delay 0 to 600 s 0.01 F001 3000
" 9E57 Voltage Differential 1 Stage 2 Pickup Delay 0 to 600 s 0.01 F001 1000
" 9E58 Voltage Differential 1 Stage 3 Pickup Delay 0 to 600 s 0.01 F001 100
" 9E59 Voltage Differential 1 Stage 4 Pickup Delay 0 to 600 s 0.01 F001 20
" 9E5A Voltage Differential 1 Dropout Delay 0 to 600 s 0.01 F001 25
" 9E5B Voltage Differential 1 Stage 1 Block 0 to 4294967295 --- 1 F300 0
" 9E5D Voltage Differential 1 Stage 2 Block 0 to 4294967295 --- 1 F300 0
" 9E5F Voltage Differential 1 Stage 3 Block 0 to 4294967295 --- 1 F300 0
" 9E61 Voltage Differential 1 Stage 4 Block 0 to 4294967295 --- 1 F300 0
" 9E63 Voltage Differential 1 Target 0 to 2 --- 1 F109 0 (Self-Reset)
" 9E64 Voltage Differential 1 Events 0 to 1 --- 1 F102 0 (Disabled)
Products Address Register name Range Units Step Format Default
