2-146 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 9E65 ...Repeated for Voltage Differential 2
" 9E8A ...Repeated for Voltage Differential 3
Charge Current Compensation Settings (Read/Write Grouped Setting)
L60 9EF0 Charging Current Compensation Factor 0 to 1 --- 1 F102 0 (Disabled)
" 9EF1 Charging Current Compensation Block 0 to 4294967295 --- 1 F300 0
" 9EF3 Charging Current Compensation Positive-
Sequence Xc
0.1 to 65.535 kOhm 0.001 F001 100
" 9EF4 Charging Current Compensation Zero-
Sequence Xc
0.1 to 65.535 kOhm 0.001 F001 100
Undercurrent (Read/Write Grouped Setting)
M60 9F00 Undercurrent (Speed 1) Function 0 to 1 --- 1 F102 0 (Disabled)
" 9F01 Undercurrent (Speed 1) Start Block Delay 0 to 600 s 0.01 F001 50
" 9F02 Undercurrent (Speed 1) Alarm Pickup 0.1 to 0.95 × FLA 0.01 F001 70
" 9F03 Undercurrent (Speed 1) Alarm Pickup Delay 0 to 600 s 0.01 F001 200
" 9F04 Undercurrent (Speed 1) Trip Pickup 0.1 to 0.95 × FLA 0.01 F001 70
" 9F05 Undercurrent (Speed 1) Trip Pickup Delay 0 to 600 s 0.01 F001 100
" 9F06 Undercurrent (Speed 1) Trip Reset Delay 0 to 600 s 0.01 F001 100
" 9F07 Undercurrent (Speed) 1 Block 0 to 4294967295 --- 1 F300 0
" 9F09 Undercurrent Target 0 to 2 --- 1 F109 0 (Self-reset)
" 9F0A Undercurrent Events 0 to 1 --- 1 F102 0 (Disabled)
" 9F0B Undercurrent Speed 2 Start Block Delay 0. to 600 s 0.01 F001 50
" 9F0C Undercurrent Speed 2 Alarm Pickup 0.1 to 0.95 × FLA 0.01 F001 70
" 9F0D Undercurrent Speed 2 Alarm Pickup Delay 0 to 600 s 0.01 F001 200
" 9F0E Undercurrent Speed 2 Trip Pickup 0.1 to 0.95 × FLA 0.01 F001 70
" 9F0F Undercurrent Speed 2 Trip Pickup Delay 0 to 600 s 0.01 F001 100
" 9F10 Undercurrent Speed 2 Trip Reset Delay 0 to 600 s 0.01 F001 100
" 9F11 Undercurrent Speed 2 Block 0 to 4294967295 --- 1 F300 0
" 9F13 Reserved (2 items) 0 to 1 --- 1 F001 0
Cold Load Pickup (Read/Write Setting) (2 or 6 Modules)
F35, F60 9F30 Cold Load Pickup 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 9F31 Cold Load Pickup 1 Initiate 0 to 4294967295 --- 1 F300 0
" 9F33 Cold Load Pickup 1 Block 0 to 4294967295 --- 1 F300 0
" 9F35 Outage Time Before Cold Load Pickup 1 0 to 1000 s 1 F001 1000
" 9F36 On Load Time Before Reset 1 0 to 1000000 s 0.001 F003 100000
" 9F38 Cold Load Pickup 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" 9F39 Cold Load Pickup 1 Reserved 0 to 65535 --- 1 F001 0
" 9F3A ...Repeated for Cold Load Pickup 2
F35 9F44 ...Repeated for Cold Load Pickup 3
" 9F4E ...Repeated for Cold Load Pickup 4
" 9F58 ...Repeated for Cold Load Pickup 5
" 9F62 ...Repeated for Cold Load Pickup 6
B90 Direct Outputs (Read/Write Setting) (256 Modules)
B90 A000 Direct Output 1 Operand 0 to 4294967295 --- 1 F300 0
" A002 Direct Output 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" A003 ...Repeated for Direct Output 2
" A006 ...Repeated for Direct Output 3
" A009 ...Repeated for Direct Output 4
Products Address Register name Range Units Step Format Default

GE b30 Specifications

General

Model	b30
Manufacturer	GE
Coil Voltage	N/A (Solid State Relay)
Coil Power	N/A (Solid State Relay)
Mechanical Life	N/A (Solid State Relay)
Electrical Life	N/A (Solid State Relay)
