2-176 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" D357 IEC 61850 GGIO2.CF.SPCSO56.ctlModel
Value
0 to 2 --- 1 F001 1
" D358 IEC 61850 GGIO2.CF.SPCSO57.ctlModel
Value
0 to 2 --- 1 F001 1
" D359 IEC 61850 GGIO2.CF.SPCSO58.ctlModel
Value
0 to 2 --- 1 F001 1
" D35A IEC 61850 GGIO2.CF.SPCSO59.ctlModel
Value
0 to 2 --- 1 F001 1
" D35B IEC 61850 GGIO2.CF.SPCSO60.ctlModel
Value
0 to 2 --- 1 F001 1
" D35C IEC 61850 GGIO2.CF.SPCSO61.ctlModel
Value
0 to 2 --- 1 F001 1
" D35D IEC 61850 GGIO2.CF.SPCSO62.ctlModel
Value
0 to 2 --- 1 F001 1
" D35E IEC 61850 GGIO2.CF.SPCSO63.ctlModel
Value
0 to 2 --- 1 F001 1
" D35F IEC 61850 GGIO2.CF.SPCSO64.ctlModel
Value
0 to 2 --- 1 F001 1
Synchrocheck (Read/Write Setting) (4, 6, or 10 Modules)
C60, D30, D60,
F60, G30, G60,
L30, L60, L90,
N60, T60
D430 Synchrocheck 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" D431 Synchrocheck 1 V1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" D432 Synchrocheck 1 V2 Source 0 to 5 --- 1 F167 1 (SRC 2)
" D433 Synchrocheck 1 Maximum Voltage
Difference
0 to 400000 V 1 F060 10000
" D435 Synchrocheck 1 Maximum Angle
Difference
0 to 100 degrees 1 F001 30
" D436 Synchrocheck 1 Maximum Frequency
Difference
0 to 2 Hz 0.01 F001 100
" D437 Synchrocheck 1 Maximum Frequency
Hysteresis
0 to 0.1 Hz 0.01 F001 6
" D438 Synchrocheck 1 Sync Close 0 to 4294967295 --- 1 F300 0
" D43A Synchrocheck 1 S-CLS Maximum dF 0.1 to 2 Hz 0.01 F001 50
" D43B Synchrocheck 1 S-CLS Minimum dF 0.01 to 1 Hz 0.01 F001 10
" D43C Synchrocheck 1 S-CLS Brk Time 0.01 to 0.5 s 0.001 F001 35
" D43D Synchrocheck 1 V2 Magnitude Correction
Factor
0.1 to 10 --- 0.01 F001 100
" D43E Synchrocheck 1 V2 Angle Shift -180 to 180 --- 1 F002 0
" D43F Synchrocheck 1 Dead Source Select 0 to 5 --- 1 F176 1 (LV1 and
DV2)
" D440 Synchrocheck 1 Dead V1 Maximum
Voltage
0.04 to 1.25 pu 0.01 F001 30
" D441 Synchrocheck 1 Dead V2 Maximum
Voltage
0.04 to 1.25 pu 0.01 F001 30
" D442 Synchrocheck 1 Live V1 Minimum Voltage 0.04 to 1.25 pu 0.01 F001 70
" D443 Synchrocheck 1 Live V2 Minimum Voltage 0.04 to 1.25 pu 0.01 F001 70
" D444 Synchrocheck 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" D445 Synchrocheck 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" D446 Synchrocheck 1 Block 0 to 4294967295 --- 1 F300 0
" D448 ...Repeated for Synchrocheck 2
" D460 ...Repeated for Synchrocheck 3
Products Address Register name Range Units Step Format Default
