CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-177
2
" D478 ...Repeated for Synchrocheck 4
C60, D60, L90,
N60, T60
D490 ...Repeated for Synchrocheck 5
" D4A8 ...Repeated for Synchrocheck 6
C60, D60, L90 D4C0 ...Repeated for Synchrocheck 7
" D4D8 ...Repeated for Synchrocheck 8
" D4F0 ...Repeated for Synchrocheck 9
" D508 ...Repeated for Synchrocheck 10
Field Unit Shared Inputs (Read/Write Setting) (16 Modules)
All except B90,
L60
D5C0 Field Shared Input 1 ID 0 to 65535 --- 1 F636 "SI 1"
" D5CA Field Shared Input 1 Unit Origin 1 0 to 8 --- 1 F256 0 (None)
" D5CB Field Shared Input 1 Channel Origin 1 1 to 15 --- 1 F001 1
" D5CC Field Shared Input 1 Events 0 to 1 --- 1 F102 1 (Enabled)
" D5CD ...Repeated for Field Shared Input 2
" D5DA ...Repeated for Field Shared Input 3
" D5E7 ...Repeated for Field Shared Input 4
" D5F4 ...Repeated for Field Shared Input 5
" D601 ...Repeated for Field Shared Input 6
" D60E ...Repeated for Field Shared Input 7
" D61B ...Repeated for Field Shared Input 8
" D628 ...Repeated for Field Shared Input 9
" D635 ...Repeated for Field Shared Input 10
" D642 ...Repeated for Field Shared Input 11
" D64F ...Repeated for Field Shared Input 12
" D65C ...Repeated for Field Shared Input 13
" D669 ...Repeated for Field Shared Input 14
" D676 ...Repeated for Field Shared Input 15
" D683 ...Repeated for Field Shared Input 16
Field Unit Shared Outputs (Read/Write Setting) (16 Modules)
All except B90,
L60
D690 Field Shared Output 1 ID 0 to 65535 --- 1 F636 "SO 1"
" D69A Field Shared Output 1 Operate 0 to 4294967295 --- 1 F300 0
" D69C Field Shared Output 1 Unit Dest 1 0 to 8 --- 1 F256 0 (None)
" D69D Field Shared Output 1 Channel Dest 1 1 to 15 --- 1 F001 1
" D69E Field Shared Output 1 Unit Dest 2 0 to 8 --- 1 F256 0 (None)
" D69F Field Shared Output 1 Channel Dest 2 1 to 15 --- 1 F001 1
" D6A0 Field Shared Output 1 Events 0 to 1 --- 1 F102 1 (Enabled)
" D6A1 ...Repeated for Field Shared Output 2
" D6B2 ...Repeated for Field Shared Output 3
" D6C3 ...Repeated for Field Shared Output 4
" D6D4 ...Repeated for Field Shared Output 5
" D6E5 ...Repeated for Field Shared Output 6
" D6F6 ...Repeated for Field Shared Output 7
" D707 ...Repeated for Field Shared Output 8
" D718 ...Repeated for Field Shared Output 9
" D729 ...Repeated for Field Shared Output 10
" D73A ...Repeated for Field Shared Output 11
Products Address Register name Range Units Step Format Default
