" D74B ...Repeated for Field Shared Output 12
" D75C ...Repeated for Field Shared Output 13
" D76D ...Repeated for Field Shared Output 14
" D77E ...Repeated for Field Shared Output 15
" D78F ...Repeated for Field Shared Output 16
DCmA Inputs (Read/Write Setting) (24 Modules)
All except B90 D7A0 DCmA Inputs 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" D7A1 DCmA Inputs 1 ID --- --- --- F205 “DCmA Ip 1"
" D7A7 Reserved 1 (4 items) 0 to 65535 --- 1 F001 0
" D7AB DCmA Inputs 1 Units --- --- --- F206 “mA”
" D7AE DCmA Inputs 1 Range 0 to 6 --- 1 F173 6 (4 to 20
mA)
" D7AF DCmA Inputs 1 Minimum Value -9999.999 to
9999.999
--- 0.001 F004 4000
" D7B1 DCmA Inputs 1 Maximum Value -9999.999 to
9999.999
--- 0.001 F004 20000
" D7B3 ...Repeated for DCmA Inputs 2
" D7C6 ...Repeated for DCmA Inputs 3
" D7D9 ...Repeated for DCmA Inputs 4
" D7EC ...Repeated for DCmA Inputs 5
" D7FF ...Repeated for DCmA Inputs 6
" D812 ...Repeated for DCmA Inputs 7
" D825 ...Repeated for DCmA Inputs 8
" D838 ...Repeated for DCmA Inputs 9
" D84B ...Repeated for DCmA Inputs 10
" D85E ...Repeated for DCmA Inputs 11
" D871 ...Repeated for DCmA Inputs 12
" D884 ...Repeated for DCmA Inputs 13
" D897 ...Repeated for DCmA Inputs 14
" D8AA ...Repeated for DCmA Inputs 15
" D8BD ...Repeated for DCmA Inputs 16
" D8D0 ...Repeated for DCmA Inputs 17
" D8E3 ...Repeated for DCmA Inputs 18
" D8F6 ...Repeated for DCmA Inputs 19
" D909 ...Repeated for DCmA Inputs 20
" D91C ...Repeated for DCmA Inputs 21
" D92F ...Repeated for DCmA Inputs 22
" D942 ...Repeated for DCmA Inputs 23
" D955 ...Repeated for DCmA Inputs 24
DNP/IEC Points (Read/Write Setting)
All D968 DNP/IEC 60870-5-104 Binary Input Points
(256 items)
0 to 4294967295 --- 1 F300 0
" DB68 DNP/IEC 60870-5-104 Analog Input Points
(256 items)
0 to 65535 --- 1 F600 0
Phasor Measurement Unit Basic Configuration (Read/Write Setting) (1, 2, or 6 Modules)
C60, D60, F60,
G60, L30, L90,
N60, T60
DCB4 PMU 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" DCB5 PMU 1 LDInst --- --- --- F214 "PMUx"
