2-18 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 070B IEC103 ASDU 1 Analog Parameter 2 0 to 65535 --- 1 F600 0
" 070C IEC103 ASDU 1 Analog Factor 2 0 to 65.535 --- 0.001 F001 1000
" 070D IEC103 ASDU 1 Analog Offset 2 -32768 to 32767 --- 1 F002 0
" 070E IEC103 ASDU 1 Analog Parameter 3 0 to 65535 --- 1 F600 0
" 070F IEC103 ASDU 1 Analog Factor 3 0 to 65.535 --- 0.001 F001 1000
" 0710 IEC103 ASDU 1 Analog Offset 3 -32768 to 32767 --- 1 F002 0
" 0711 IEC103 ASDU 1 Analog Parameter 4 0 to 65535 --- 1 F600 0
" 0712 IEC103 ASDU 1 Analog Factor 4 0 to 65.535 --- 0.001 F001 1000
" 0713 IEC103 ASDU 1 Analog Offset 4 -32768 to 32767 --- 1 F002 0
" 0714 IEC103 ASDU 1 Analog Parameter 5 0 to 65535 --- 1 F600 0
" 0715 IEC103 ASDU 1 Analog Factor 5 0 to 65.535 --- 0.001 F001 1000
" 0716 IEC103 ASDU 1 Analog Offset 5 -32768 to 32767 --- 1 F002 0
" 0717 IEC103 ASDU 1 Analog Parameter 6 0 to 65535 --- 1 F600 0
" 0718 IEC103 ASDU 1 Analog Factor 6 0 to 65.535 --- 0.001 F001 1000
" 0719 IEC103 ASDU 1 Analog Offset 6 -32768 to 32767 --- 1 F002 0
" 071A IEC103 ASDU 1 Analog Parameter 7 0 to 65535 --- 1 F600 0
" 071B IEC103 ASDU 1 Analog Factor 7 0 to 65.535 --- 0.001 F001 1000
" 071C IEC103 ASDU 1 Analog Offset 7 -32768 to 32767 --- 1 F002 0
" 071D IEC103 ASDU 1 Analog Parameter 8 0 to 65535 --- 1 F600 0
" 071E IEC103 ASDU 1 Analog Factor 8 0 to 65.535 --- 0.001 F001 1000
" 071F IEC103 ASDU 1 Analog Offset 8 -32768 to 32767 --- 1 F002 0
" 0720 IEC103 ASDU 1 Analog Parameter 9 0 to 65535 --- 1 F600 0
" 0721 IEC103 ASDU 1 Analog Factor 9 0 to 65.535 --- 0.001 F001 1000
" 0722 IEC103 ASDU 1 Analog Offset 9 -32768 to 32767 --- 1 F002 0
" 0723 ...Repeated for IEC103 ASDU 2
" 0742 ...Repeated for IEC103 ASDU 3
" 0761 ...Repeated for IEC103 ASDU 4
IEC103 Commands (Read/Write Setting) (32 Modules)
All 0780 IEC103 Command 1 FUN 0 to 255 --- 1 F001 0
" 0781 IEC103 Command 1 INF 0 to 255 --- 1 F001 0
" 0782 IEC103 Command 1 Param ON 0 to 64 --- 1 F631 0 (OFF)
" 0783 IEC103 Command 1 Param OFF 0 to 64 --- 1 F631 0 (OFF)
" 0784 ...Repeated for IEC103 Command 2
" 0788 ...Repeated for IEC103 Command 3
" 078C ...Repeated for IEC103 Command 4
" 0790 ...Repeated for IEC103 Command 5
" 0794 ...Repeated for IEC103 Command 6
" 0798 ...Repeated for IEC103 Command 7
" 079C ...Repeated for IEC103 Command 8
" 07A0 ...Repeated for IEC103 Command 9
" 07A4 ...Repeated for IEC103 Command 10
" 07A8 ...Repeated for IEC103 Command 11
" 07AC ...Repeated for IEC103 Command 12
" 07B0 ...Repeated for IEC103 Command 13
" 07B4 ...Repeated for IEC103 Command 14
" 07B8 ...Repeated for IEC103 Command 15
" 07BC ...Repeated for IEC103 Command 16
