CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-19
2
" 07C0 ...Repeated for IEC103 Command 17
" 07C4 ...Repeated for IEC103 Command 18
" 07C8 ...Repeated for IEC103 Command 19
" 07CC ...Repeated for IEC103 Command 20
" 07D0 ...Repeated for IEC103 Command 21
" 07D4 ...Repeated for IEC103 Command 22
" 07D8 ...Repeated for IEC103 Command 23
" 07DC ...Repeated for IEC103 Command 24
" 07E0 ...Repeated for IEC103 Command 25
" 07E4 ...Repeated for IEC103 Command 26
" 07E8 ...Repeated for IEC103 Command 27
" 07EC ...Repeated for IEC103 Command 28
" 07F0 ...Repeated for IEC103 Command 29
" 07F4 ...Repeated for IEC103 Command 30
" 07F8 ...Repeated for IEC103 Command 31
" 07FC ...Repeated for IEC103 Command 32
Digital Counter States Actual Values (Read Only Non-Volatile) (8 Modules)
All except B90 0800 Digital Counter 1 Value -2147483647 to
2147483647
--- 1 F004 0
" 0802 Digital Counter 1 Frozen -2147483647 to
2147483647
--- 1 F004 0
" 0804 Digital Counter 1 Frozen Time Stamp 0 to 4294967295 --- 1 F050 0
" 0806 Digital Counter 1 Frozen Time Stamp us 0 to 4294967295 --- 1 F003 0
" 0808 ...Repeated for Digital Counter 2
" 0810 ...Repeated for Digital Counter 3
" 0818 ...Repeated for Digital Counter 4
" 0820 ...Repeated for Digital Counter 5
" 0828 ...Repeated for Digital Counter 6
" 0830 ...Repeated for Digital Counter 7
" 0838 ...Repeated for Digital Counter 8
FlexStates (Read Only)
All 0900 FlexState Bits (16 items) 0 to 65535 --- 1 F001 0
RxGOOSE Boolean (Read/Write Setting) (256 Modules)
All 0912 RxGOOSE Boolean 1 Default State 0 to 3 --- 1 F086 0 (Off)
" 0913 RxGOOSE Boolean 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 0914 ...Repeated for RxGOOSE Boolean 2
" 0916 ...Repeated for RxGOOSE Boolean 3
" 0918 ...Repeated for RxGOOSE Boolean 4
" 091A ...Repeated for RxGOOSE Boolean 5
" 091C ...Repeated for RxGOOSE Boolean 6
" 091E ...Repeated for RxGOOSE Boolean 7
" 0920 ...Repeated for RxGOOSE Boolean 8
" 0922 ...Repeated for RxGOOSE Boolean 9
" 0924 ...Repeated for RxGOOSE Boolean 10
" 0926 ...Repeated for RxGOOSE Boolean 11
" 0928 ...Repeated for RxGOOSE Boolean 12
" 092A ...Repeated for RxGOOSE Boolean 13
Products Address Register name Range Units Step Format Default

GE b30 Specifications

General

Model	b30
Manufacturer	GE
Coil Voltage	N/A (Solid State Relay)
Coil Power	N/A (Solid State Relay)
Mechanical Life	N/A (Solid State Relay)
Electrical Life	N/A (Solid State Relay)
