GE b30 Communications Guide

CHAPTER 3: IEC 61850 COMMUNICATION MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-189
3
3.5.5.5 Energy metering (EnrMtr)
This element is instantiated in the following products: C60, D60, F35, F60, G30, G60, L90, M60, N60, T60.
Table 3-201: Energy metering data objects
units.SIUnit ENUMERATED 61 is unit for apparent power in volt-
ampere
R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
LNName: EnrMtrMMTR# LDevice inst: Meter UR element: Signal Source # Energy Metering
data obj. data attribute Type FC UR Name Description R/W/C
PosTotWh MV SRC # Total Watt-hour in positive
direction
R
instMag AnalogueValue MX R
instMag.f FLOAT32 SRC # POS WATTHOUR R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 72, the code for real energy in watt hours
(Wh)
R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF EnrMtrMMTR#.PosTotWh.db R/W/C
NegTotWh MV SRC # Total Watt-hour in negative
direction
R
instMag AnalogueValue MX R
instMag.f FLOAT32 SRC # NEG WATTHOUR R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 72, the code for real energy in watt hours
(Wh)
R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF EnrMtrMMTR#.NegTotWh.db R/W/C
PosTotVArh MV SRC # Total VAr-hour in positive direction R
instMag AnalogueValue MX R
instMag.f FLOAT32 SRC # T POS VARHOUR R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 73, the code for reactive energy in volt
ampere hours (VArh)
R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF EnrMtrMMTR#.PosTotVArh.db R/W/C
NegTotVAr
h
MV SRC # Total VAr-hour in negative directionR
instMag AnalogueValue MX R
instMag.f FLOAT32 SRC # NEG VARHOUR R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 73, the code for reactive energy in volt
ampere hours (VArh)
R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF EnrMtrMMTR#.NegTotVArh.db R/W/C
LNName: DmdMtrMMTR# LDevice inst: Meter UR element: Signal Source # NAME Demand Metering
data obj. data attribute Type FC UR Name Description R/W/C
