3-212 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
CompLevel MV Indicates the level of the broken rotor bar spectral component relative to the
spectral component of the system frequency.
The COMPONENT LEVEL in dB.
BknRotSVBR
ConfRev ING Expected value of confRev field in messages subscribed to by RxGOOSE# LGOS
CrcFail1 SPS The CRC error threshold has been exceeded.
The 87L DIFF CH 1 CRCFAIL operand, which becomes On when the differential
element has detected the CRC error threshold has been exceeded on channel 1.
LinDfPDIF
Ctrl SPS Asserted for one second upon any transition in any mode LoVStrGAPC
CurUnb MV % UNBALANCE CURRENT AmpUnbPTOC
Day1 SPS Current day, where 1 = Sunday. The DAY operand. TmDayGAPC
DayofMonth INS Represents the day of current month (range 1 to 31).
The DayOfMonth Actual Value to represent in date of month in number form.
TmDayGAPC
DayofYear INS Represents the day of the year (range 1 to 366).
The DayOfYear Actual Value to represent day of year in number form.
TmDayGAPC
DbMax1 ASG Value of “max.” in deadband calculations FTDRsGGIO1, GGIO4
DbMin1 ASG Value of “min.” in deadband calculations FTDRsGGIO1, GGIO4
Deactivated SPS Indicates PUSHBUTTON # OFF state. When user pushbutton is asserted, status is
"false"; when user pushbutton is released, status is "true."
The PUSHBUTTON 1 OFF operand.
UsrPbIHMI
DeaV1 SPS This data object indicates that V1 is below the DeaVal1 setting.
The SYNC 1 V1 BELOW MAX operand.
SynChkRSYN
DeltaOut MV PID Delta Output value PIDRegFPID
DifA2ndH WYE Phase differential current PctDifPDIF
DifA5thH WYE Phase differential current PctDifPDIF
DifVPh WYE Differential voltage in per unit for phase A, B, and C VDifPDIF
DirSupn SPS Directional overcurrent supervision status (not instantiated for zone 1
GndDisPDIS1).
The GND DIST Z2 DIR SUPN operand.
GndDisPDIS
Disabled SPS Function is disabled Rec13pRREC, Rec3pRREC
DisArmed SPS Indicates the high impedance fault detection element is in disarmed state HiZPHIZ
DischargeTms MV Capacitor discharge time in seconds.
CAP 1 DISCHARGE TIME in seconds.
CapCtlGAPC
Discharging SPS Capacitor bank is discharging.
CAP 1 DISCHARGING operand.
CapCtlGAPC
DistDet SPS Sensitive current disturbance detector.
For PwrSwgRPSB1, power swing element detected disturbance other than power
swing.
The 50DD SV operand, which becomes On when the 87L disturbance detector has
operated.
The POWER SWING 50DD operand.
LinDfPDIF, PwrSwgRPSB
