GE b30 Communications Guide

CHAPTER 3: IEC 61850 COMMUNICATION MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-213
3
Dpo SPS The DPO (dropout) operand.
Inverse of Str, Op, or Pkp.
AcdEnrPIOC, AgeSPTR,
AmpUnbPTOC,
AuxOvPTOV, AuxUvPTUV,
B_IocPIOC, B_EfpPIOC,
B_TocPTOC, B_UvPTUV,
BusDifPDIF, CBArc0SCBR,
Cmp8BtGAPC,
CmpOvPTOV, CPhOvPTOV,
DigElGAPC, FldAmpPTOC,
FldAmpPTUC,
FldGnd0PHIZ,
FldGnd1PHIZ,
FldGnd2PHIZ, FlshOvPIOC,
FlxElGAPC, GndIocPIOC,
GndTocPTOC,
GnUnb$PTOC,
GnUnbPTOC,
Ha3NUvPTUV, HiZPHIZ,
HPTmpSPTR, HzBnd$PTUF,
LinPkpPIOC, LodEncPDIS,
LosExtPDIS, LosExt1PDIS1,
LosExt2PDIS,
MAccTmPMSS,
MecJamPMSS,
MotThmPTTR, NeAUnPTOC,
NegIocPIOC, NegOvPTOV,
NegTocPTOC, NeuIocPIOC,
NeuTocPTOC, NeuOvPTOV,
NuVUnPTOV OvHzPTOF,
PhAUnPTOC, PhCmp1PDIF,
PhsIocPIOC, PhsOvPTOV,
PhsTocPTOC, PhsUvPTUV,
PRTDsSTMP, RgDifPDIF,
RRTDsSTMP, RteHzPFRC,
S2AcTmPMSS1, SenPDOP,
Sen1PDOP, Sen2PDOP,
SpltPhPDIF, Statr$PHIZ,
StatrPHIZ, StrRtePMRI,
SubHa$PHIZ, SubHaPHIZ,
TmBtwnPMRI, UnHzPTUF,
UnPwrPDUP, VDifPDIF,
VpHzPVPH, VtffGAPC
DpoAlm SPS Inverse of alarm Pkp.
RRTD RTD 1 ALARM DPO operand.
RTD Ip 1 ALARM DPO operand.
UNDERPWR 1 ALARM DPO operand.
PRTDsSTMP, RRTDsSTMP,
UnPwrPDUP
DpoBia SPS B90 Drop-out of Biased indicates the dropping of pick-up condition for biased
differential element
B_DifPDIF
DpoCls SPS Inverse of close pkp.
The AVR CLOSE 1 DPO operand.
AvrGAPC
DpoOpn SPS Inverse of open pkp.
The AVR OPEN 1 DPO operand.
AvrGAPC
DpoPhsφ SPS Split phase SpltPhPDIF
DpoPhs1 SPS Inverse of per phase pickup (Pkp).
Individual phase DPO (dropout) operand.
BusDifPDIF, PhsIocPIOC,
B_TocPTOC, FlshOvPIOC,
GndDisPDIS, PhsDisPDIS,
PhsTocPTOC, SttDifPDIF
DpoPhs1 SPS Inverse of Op PhsIocPIOC, PhsOvPTOV,
PhsUvPTUV
DrcDevOff SPS A direct device is configured but not connected.
The DIRECT DEVICE OFF operand.
LPHD
DrcRingBrk SPS The Direct I/O settings is for a ring but the connection is not in a ring.
The DIRECT RING BREAK operand.
LPHD
DwnCond ACT Indicates the high impedance fault downed conductor element has operated HiZPHIZ
Data object
name
CDC Semantics Used in logical nodes…
