GE b30 Communications Guide

3-214 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
DynArmd SPS This data object indicates that dynamic mode is armed.
The SYNC1 S-CLOSE ARMD operand, which becomes On when dynamic mode is
armed.
SynChkRSYN
DynDpo SPS The SYNC1 S-CLOSE DPO operand, which becomes Off when all criteria for
dynamic mode are fulfilled
SynChkRSYN
DynOp SPS This data object indicates that all criteria for dynamic mode are fulfilled if value is
TRUE else false.
The SYNC1 S-CLOSE OP operand, which becomes On when all criteria for dynamic
mode are fulfilled.
SynChkRSYN
Ena1 SPS Function is Enabled.
The AR ENABLED operand.
Rec13pRREC, Rec3pRREC
EqLim SPS The number of pulses counted is equal to the set number.
Counter 1(CNT1) EQL operand, which indicates the number of pulses counted is
equal to the set number.
DigCntFCNT
EqpMismat SPS The configuration of modules does not match the stored order code.
The EQUIPMENT MISMATCH operand.
LPHD
EvtEna1 ENG Setting to enable generation of events in event record, 0 = Disabled, 1 = Enabled GGIO3
EvtLED SPS An LED - Event Cause LED status. For graphical front panel.
The EVENT CAUSE LED 1 operand.
LEDsIHMI
EvtRcdClr SPC Clear Event Records (erase all Events).
The CLEAR EVENT RECORDS command.
Master/LLN0
Fail SPS Ground Protection Module Failure.
GPM-F (Field Ground Protection Module) Fail status.
The GPM-F FAILURE operand.
FldGnd0PHIZ
FDLOp SPS Overcurrent fault detector low has operated.
The 87PC FDL OP operand.
PhCmp1PDIF
FlexErrTkn SPS A FlexLogic equation is incorrect.
The FLEXLOGIC ERR TOKEN operand.
LPHD
Flt3Ph SPS Fault indication - Three phase fault.
The PHASE SELECT 3P operand.
PhSelGAPC
FltAB SPS Fault indication - Phase A to B.
The PHASE SELECT AB operand.
PhSelGAPC
FltABG SPS Fault indication - Phase A to B to ground.
The PHASE SELECT ABG operand.
PhSelGAPC
FltAG SPS Fault indication - Phase A to ground.
The PHASE SELECT AG operand.
PhSelGAPC
FltBC SPS Fault indication - Phase B to C.
The PHASE SELECT BC operand.
PhSelGAPC
FltBCG SPS Fault indication - Phase B to C to ground.
The PHASE SELECT BCG operand.
PhSelGAPC
FltBG SPS Fault indication - Phase B to ground.
The PHASE SELECT BG operand.
PhSelGAPC
FltCA SPS Fault indication - Phase C to A.
The PHASE SELECT CA operand.
PhSelGAPC
FltCAG SPS Fault indication - Phase C to A to ground.
The PHASE SELECT CAG operand.
PhSelGAPC
FltCG SPS Fault indication - Phase C to ground.
The PHASE SELECT CG operand.
PhSelGAPC
FltCntClr SPC TRUE = clear incipient fault count. The clear incipient fault counters command. ICFltPTEF
FltCntPhφ INS Number of detected incipient faults.
INCIPIENT FAULT 1 PH A/B/C FAULTS.
ICFltPTEF
FltLinID VSS Faulted line ID FltRFLO
FltLocation MV Fault location in percentage.
The FAULT LOCATION in percentage of field winding from negative terminal in
case of single point injection. If double point injection, displays Invalid value.
FldGnd0PHIZ
FltLoopReact MV D30, D60, L60, L90 - The fault loop reactance FltRFLO
Data object
name
CDC Semantics Used in logical nodes…
