CHAPTER 3: IEC 61850 COMMUNICATION MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-223
3
Trouble SPS Trouble operand or LED.
The LED TROUBLE operand.
The SH STAT GND TRB OP operand.
SubHaPHIZ, LEDsIHMI
Tx1 SPS Transmit signal.
The DCUB TX1 operand.
The DUTT TX1 operand.
The HYBRID POTT TX1 operand.
The POTT1 TX1 operand.
The PUTT TX1 operand.
DCUB_PSCH, DUTT_PSCH,
HPOTT_PSCH, POTT_PSCH,
POTT1_PSCH, PUTT_PSCH
TxStop1 SPS Transmit signal stop.
The DIR BLOCK1 TX1 STOP operand.
DCB_PSCH, DCB1_PSCH
UnA1 SPS Undercurrent pickup.
This operand operates when an open pole condition is detected due to
undercurrent in phase A, B, or C.
The OPEN POLE I< phase A/B/C operand.
LinPkpPIOC, OpnPlΘSCBR
UNotPrgm SPS The Product Setup > Installation > Relay Settings setting is not programmed.
The UNIT NOT PROGRAMMED operand.
LPHD
UnV SPS Undervoltage pickup.
The LINE PICKUP UV PKP operand.
LinPkpPIOC
UpdateTms ING Periodic update time Master/LLN0
UsrPrgmLED1 SPS LED indication - User Programmable LED status. For enhanced and standard front
panels.
The LED USER 1 operand.
LEDsIHMI
V1Src CMV V1 Voltage phasor.
SYNCHROCHECK 1 V1 voltage phasor, in primary volts.
SynChkRSYN
V2Src CMV V2 Voltage phasor.
SYNCHROCHECK 1 V2 voltage phasor, in primary volts.
SynChkRSYN
VabRMS MV Phase AB Voltage RMS. SRC 1 Phase AB Voltage RMS, in primary Volts. ACsrcMMXU
VADmd MV Apparent power demand in VA.
SRC 1 DMD VA, in primary volt ampere.
DmdMtrMMTR
VAMaxDmdDt MV Max apparent power demand in VA with associated date/time stamp. The ClcMth
cannot be used for MAX, as the time stamp definition of IEC 61850 is different
from UR.
SRC 1 DMD VA, in primary volt ampere, with associated date, SRC 1 DMD VA DATE.
DmdMtrMMTR
VArDmd MV Reactive power demand in VAR.
SRC 1 DMD VAR, in primary volt ampere reactive.
DmdMtrMMTR
VArMaxDmdDt MV Max reactive power demand in VAR with associated date/time stamp. The ClcMth
cannot be used for MAX, as the time stamp definition of IEC 61850 is different
from UR.
SRC 1 DMD VAR, in primary volt ampere reactive, with associated date, SRC 1
DMD VAR DATE.
DmdMtrMMTR
VaRMS MV Phase A Voltage RMS.
SRC 1 Phase AG Voltage RMS, in primary volts.
ACsrcMMXU
Vaux CMV Auxiliary voltage (fourth input in a voltage AC bank).
SRC 1 Auxiliary Voltage phasor, in primary volts.
ACsrcMMXN
VauxRMS MV Auxiliary voltage RMS (fourth input in a voltage AC bank).
SRC 1 Auxiliary Voltage RMS, in primary volts.
ACsrcMMXN
VbcRMS MV Phase BC Voltage RMS.
SRC 1 Phase BC Voltage RMS, in primary Volts.
ACsrcMMXU
VbRMS MV Phase B Voltage RMS.
SRC 1 Phase BG Voltage RMS, in primary volts.
ACsrcMMXU
VcaRMS MV Phase CA Voltage RMS.
SRC 1 Phase CA Voltage RMS, in primary Volts.
ACsrcMMXU
VcRMS MV Phase A Voltage RMS.
SRC 1 Phase CG Voltage RMS, in primary volts.
ACsrcMMXU
VolLoc CMV Composite Voltage at the Local Terminal. Local Vcomp phasor, in primary volts. VCompMMXU
Data object
name
CDC Semantics Used in logical nodes…
