3-222 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
TagOn SPS Breaker tagged.
The BREAKER 1 TAG ON operand.
Bkr0XCBR
TagOff SPS Breaker not tagged.
The BREAKER 1 TAG OFF operand.
Bkr0XCBR
TapLocFlt SPS L90 - The fault is identified between the local terminal and the tap point.
The TAP-LOCAL FAULT operand.
FltRptRFLO
TdrTrbl SPS TDR trouble.
The TDR TROUBLE operand.
LPHD
TempMnt SPS The ambient temperature is greater than the maximum operating temperature.
The TEMP MONITOR operand.
LPHD
TestMod SPS LED indication - Relay in Test Mode.
The LED TEST MODE operand.
LEDsIHMI
TestPrgInd SPS LED indication - Test In-Progress.
The LED TEST IN PROGRESS operand.
LEDsIHMI
ThmCap MV % thermal model motor unbalance.
MOTOR THERMAL CAPACITY USED in percentage (%).
MotThmPTTR
ThmLOTm MV Indicates Thermal Lockout for the motor.
THERMAL LOCKOUT TIME in seconds.
MotThmPTTR
ThrdEthFail SPS Third Ethernet failure.
The THIRD ETHERNET FAIL operand.
LPHD
TmChgOp1 SPS Change in round trip delay on the channel exceeded pre-set value.
87L DIFF CH 1 TIME CHNG operand, which becomes On when the Change in round
trip delay on channel 1 exceeded preset value.
LinDfPDIF
TmnsDelta MV PTP-IRIG-B Delta in ns TmClkLTMS
TmOfClc INS Represents the UTC time of the broken rotor bar calculation in seconds elapsed
since 1970/01/01, 00.00.00.
The TIME OF BRB CALC. actual value.
BknRotSVBR
TmOfMax INS The TIME OF MAXIMUM BRB actual value BknRotSVBR
TmStr1 SPS Power swing timer picked up.
The POWER SWING TMR2 PKP operand.
PwrSwgRPSB
ToOilTmp MV Indicates top oil temperature.
The TOP OIL degrees C actual value.
HPTmpSPTR
TotLOTm MV Indicates total lockout time for the motor. TOTAL MOTOR LOCKOUT TIME in
seconds.
MotThmPTTR
Tr1p ACT Single pole trip operation initiated.
The 87L TRIP 1P OP operand.
General is TRIP 1-POLE operand, phsA is TRIP PHASE A operand, phsB is TRIP
PHASE B operand, and phsC is TRIP PHASE C operand.
LinDfPDIF, TrOutPTRC
Tr3p ACT Three pole trip operation initiated.
The DCUB TRIP 3P operand.
The DIR BLOCK1 TRIP 3P operand.
The DUTT TRIP 3P operand.
The HYBRID POTT TRIP 3P operand.
The 87L TRIP 3P OP operand.
The POTT1 TRIP 3P operand.
The PUTT TRIP 3P operand.
The TRIP 3-POLE operand.
DCB_PSCH, DCB1_PSCH,
DCUB_PSCH, DUTT_PSCH,
HPOTT_PSCH, LinDfPDIF,
POTT_PSCH, POTT1_PSCH,
PUTT_PSCH, TrOutPTRC
Tr3pFrcd SPS Three pole trip mode is being forced.
The TRIP FORCE 3-POLE operand (3-pole trip mode is being forced).
TrOutPTRC
TransBlk SPS Phase comparison transient blocking has operated.
The 87PC TRANS BLOCK OP operand.
PhCmp1PDIF
TrcHz MV B90 frequency B_FrqMMXN
Trigger11 ENS Represents the Hi-Z Data Capture 1 trigger type HiZPHIZ
Trigger21 ENS Represents the Hi-Z Data Capture 1 RMS type HiZPHIZ
TripInd SPS LED indication - Element Trip Indication.
The LED TRIP operand.
LEDsIHMI
Data object
name
CDC Semantics Used in logical nodes…
