2-28 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 160C Field Unit Online/Offline States 0 to 65535 --- 1 F500 0
" 160D Field RTD Input Trouble States 0 to 65535 --- 1 F500 0
" 160E Field Transducer Input Trouble States 0 to 65535 --- 1 F500 0
Ethernet Fibre Channel Status (Read Only)
All 1610 Ethernet Primary Fibre Channel Status 0 to 2 --- 1 F134 0 (Fail)
" 1611 Ethernet Secondary Fibre Channel Status 0 to 2 --- 1 F134 0 (Fail)
" 1612 Ethernet Tertiary Fibre Channel Status 0 to 2 --- 1 F134 0 (Fail)
Data Logger Actual Values (Read Only)
All except B90 1618 Data Logger Channel Count 0 to 16 channel 1 F001 0
" 1619 Time of Oldest Available Samples 0 to 4294967295 --- 1 F050 0
" 161B Time of Newest Available Samples 0 to 4294967295 --- 1 F050 0
" 161D Data Logger Duration 0 to 999.9 days 0.1 F001 0
Channel Status (Read Only)
L90 1620 Channel 1 Status 0 to 2 --- 1 F134 1 (OK)
" 1621 Channel 1 Number of Lost Packets 0 to 65535 --- 1 F001 0
" 1622 Channel 1 Local Loopback Status 0 to 2 --- 1 F134 2 (n/a)
" 1623 Channel 1 Remote Loopback Status 0 to 2 --- 1 F134 2 (n/a)
" 1626 Channel 1 Loop Delay 0 to 200 ms 0.1 F001 0
" 1627 Channel 2 Status 0 to 2 --- 1 F134 2 (n/a)
" 1628 Channel 2 Number of Lost Packets 0 to 65535 --- 1 F001 0
" 1629 Channel 2 Local Loopback Status 0 to 2 --- 1 F134 2 (n/a)
" 162A Channel 2 Remote Loopback Status 0 to 2 --- 1 F134 2 (n/a)
" 162B Network Status 0 to 2 --- 1 F134 2 (n/a)
" 162E Channel 2 Loop Delay 0 to 200 ms 0.1 F001 0
" 162F Channel PFLL Status 0 to 2 --- 1 F134 1 (OK)
Channel Status Commands (Read/Write Command)
L90 1630 L90 Channel Status Clear 0 to 1 --- 1 F126 0 (No)
87L Channel Status Actual Values (Read Only)
L30, L90 1638 Channel 1 Asymmetry -65.535 to 65.535 ms 0.001 F004 0
" 163A Channel 2 Asymmetry -99.999 to 99.999 ms 0.001 F004 0
L60 Test Mode (Read/Write Setting)
L60 1640 L60 Channel Test Mode 0 to 1 --- 1 F102 0 (Disabled)
L60 Test Mode (Read Only)
L60 1641 L60 Trip Control Status 0 to 2 --- 1 F134 2 (n/a)
" 1642 L60 Channel Status (4 items) 0 to 2 --- 1 F134 2 (n/a)
Stator Differential Actual Values (Read Only)
G60, M60 1660 Generator Differential Iad 0 to 999999.999 A 0.001 F060 0
" 1662 Generator Restraint Iar 0 to 999999.999 A 0.001 F060 0
" 1664 Generator Differential Ibd 0 to 999999.999 A 0.001 F060 0
" 1666 Generator Restraint Ibr 0 to 999999.999 A 0.001 F060 0
" 1668 Generator Differential Icd 0 to 999999.999 A 0.001 F060 0
" 166A Generator Restraint Icr 0 to 999999.999 A 0.001 F060 0
" 166C Stator Differential CT Primary 0 to 50000 --- 1 F060 1
Stator Ground Actual Values (Read Only)
G30, G60 1670 Stator Ground Vn 3rd 0 to 999999.999 V 0.001 F060 0
" 1672 Stator Ground Vn V0 3rd 0 to 999999.999 V 0.001 F060 0
" 1674 Stator Ground V0 3rd 0 to 999999.999 V 0.001 F060 0
Products Address Register name Range Units Step Format Default
