2-30 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 16EC ...Repeated for Frequency Rate of Change 4
Breaker Flashover (Read/Write Setting) (1 or 2 Modules)
B30, C60, C70,
D60, F35, F60,
G60, L60, L90,
M60, T60
1700 Breaker Flashover 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 1701 Breaker Flashover 1 Side 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" 1702 Breaker Flashover 1 Side 2 Source 0 to 6 --- 1 F211 0 (None)
" 1703 Breaker Flashover 1 Status Closed A 0 to 4294967295 --- 1 F300 0
" 1705 Breaker Flashover 1 Status Closed B 0 to 4294967295 --- 1 F300 0
" 1707 Breaker Flashover 1 Status Closed C 0 to 4294967295 --- 1 F300 0
" 1709 Breaker Flashover 1 Voltage Pickup Level 0.004 to 1.5 pu 0.001 F001 850
" 170A Breaker Flashover 1 Voltage Difference
Pickup Level
0 to 100000 V 1 F060 1000
" 170C Breaker Flashover 1 Current Pickup Level 0.02 to 1.5 pu 0.001 F001 600
" 170D Breaker Flashover 1 Pickup Delay 0 to 65.535 s 0.001 F001 100
" 170E Breaker Flashover 1 Supervision Phase A 0 to 4294967295 --- 1 F300 0
" 1710 Breaker Flashover 1 Supervision Phase B 0 to 4294967295 --- 1 F300 0
" 1712 Breaker Flashover 1 Supervision Phase C 0 to 4294967295 --- 1 F300 0
" 1714 Breaker Flashover 1 Block 0 to 4294967295 --- 1 F300 0
" 1716 Breaker Flashover 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 1717 Breaker Flashover 1 Target 0 to 2 --- 1 F109 0 (Self-Reset)
" 1718 Reserved (4 items) --- --- --- F001 0
B30, C60, D60,
F35, F60, G60,
L60, L90, M60,
T60
171C ...Repeated for Breaker Flashover 2
Source Current (Read Only) (2, 4, or 6 Modules)
All except B90,
C30
1800 Source 1 Phase A Current RMS 0 to 999999.999 A 0.001 F060 0
" 1802 Source 1 Phase B Current RMS 0 to 999999.999 A 0.001 F060 0
" 1804 Source 1 Phase C Current RMS 0 to 999999.999 A 0.001 F060 0
" 1806 Source 1 Neutral Current RMS 0 to 999999.999 A 0.001 F060 0
" 1808 Source 1 Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 180A Source 1 Phase A Current Angle -359.9 to 0 degrees 0.1 F002 0
" 180B Source 1 Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 180D Source 1 Phase B Current Angle -359.9 to 0 degrees 0.1 F002 0
" 180E Source 1 Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 1810 Source 1 Phase C Current Angle -359.9 to 0 degrees 0.1 F002 0
" 1811 Source 1 Neutral Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 1813 Source 1 Neutral Current Angle -359.9 to 0 degrees 0.1 F002 0
" 1814 Source 1 Ground Current RMS 0 to 999999.999 A 0.001 F060 0
" 1816 Source 1 Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 1818 Source 1 Ground Current Angle -359.9 to 0 degrees 0.1 F002 0
" 1819 Source 1 Zero Sequence Current
Magnitude
0 to 999999.999 A 0.001 F060 0
" 181B Source 1 Zero Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
" 181C Source 1 Positive Sequence Current
Magnitude
0 to 999999.999 A 0.001 F060 0
" 181E Source 1 Positive Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
