2-32 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 1A2B Source 1 Negative Sequence Voltage Angle -359.9 to 0 degrees 0.1 F002 0
" 1A2C Reserved (20 items) --- --- --- F001 0
" 1A40 ...Repeated for Source 2
B30, C60, C70,
D60, F35, F60,
G30, G60, L60,
L90, M60, N60,
T35, T60
1A80 ...Repeated for Source 3
" 1AC0 ...Repeated for Source 4
B30, C70, F35,
N60, T35, T60
1B00 ...Repeated for Source 5
" 1B40 ...Repeated for Source 6
Source Power (Read Only) (2, 4, or 6 Modules)
All except B90,
C30
1C00 Source 1 Three Phase Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
" 1C02 Source 1 Phase A Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
" 1C04 Source 1 Phase B Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
" 1C06 Source 1 Phase C Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
" 1C08 Source 1 Three Phase Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
" 1C0A Source 1 Phase A Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
" 1C0C Source 1 Phase B Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
" 1C0E Source 1 Phase C Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
" 1C10 Source 1 Three Phase Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
" 1C12 Source 1 Phase A Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
" 1C14 Source 1 Phase B Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
" 1C16 Source 1 Phase C Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
" 1C18 Source 1 Three Phase Power Factor -0.999 to 1 --- 0.001 F013 0
" 1C19 Source 1 Phase A Power Factor -0.999 to 1 --- 0.001 F013 0
" 1C1A Source 1 Phase B Power Factor -0.999 to 1 --- 0.001 F013 0
" 1C1B Source 1 Phase C Power Factor -0.999 to 1 --- 0.001 F013 0
" 1C1C Reserved (4 items) --- --- --- F001 0
" 1C20 ...Repeated for Source 2
B30, C60, C70,
D60, F35, F60,
G30, G60, L60,
L90, M60, N60,
T35, T60
1C40 ...Repeated for Source 3
" 1C60 ...Repeated for Source 4
B30, C70, F35,
N60, T35, T60
1C80 ...Repeated for Source 5
" 1CA0 ...Repeated for Source 6
Products Address Register name Range Units Step Format Default
