GE b30 Communications Guide

2-52 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 3608 Phase Current Unbalance 1 Comp Iop B 0 to 99.9999 pu 0.000
1
F004 0
" 360A Phase Current Unbalance 1 Comp Iop C 0 to 99.9999 pu 0.000
1
F004 0
" 360C ...Repeated for Phase Current Unbalance 2
" 3618 ...Repeated for Phase Current Unbalance 3
Voltage Differential Actual Values (Read Only) (3 Modules)
C70 3640 Voltage Differential 1 Bus Phase A Voltage 0 to 99.9999 pu 0.000
1
F003 0
" 3642 Voltage Differential 1 Differential Phase A
Voltage
0 to 99.9999 pu 0.000
1
F003 0
" 3644 Voltage Differential 1 Bus Phase B Voltage 0 to 99.9999 pu 0.000
1
F003 0
" 3646 Voltage Differential 1 Differential Phase B
Voltage
0 to 99.9999 pu 0.000
1
F003 0
" 3648 Voltage Differential 1 Bus Phase C Voltage 0 to 99.9999 pu 0.000
1
F003 0
" 364A Voltage Differential 1 Differential Phase C
Voltage
0 to 99.9999 pu 0.000
1
F003 0
" 364C ...Repeated for Voltage Differential 2
" 3658 ...Repeated for Voltage Differential 3
Neutral Current Unbalance Actual Values (Read Only) (3 Modules)
C70 36C4 Neutral Current Unbalance 1 Raw INsp 0 to 9.9999 pu 0.000
1
F003 0
" 36C6 Neutral Current Unbalance 1 Comp Iop 0 to 9.9999 pu 0.000
1
F003 0
" 36C8 ...Repeated for Neutral Current Unbalance
2
" 36CC ...Repeated for Neutral Current Unbalance
3
Neutral Voltage Unbalance Actual Values (Read Only) (3 Modules)
C70 36F0 Neutral Voltage Unbalance 1 Neutral Point
Vx Angle
0 to 99999.9 degrees 0.1 F004 0
" 36F2 Neutral Voltage Unbalance 1 V0 Angle 0 to 99999.9 degrees 0.1 F004 0
" 36F4 Neutral Voltage Unbalance 1 V0 Magnitude 0 to 99.9999 pu 0.000
1
F004 0
" 36F6 Neutral Voltage Unbalance 1 Neutral Point
Vx Magnitude
0 to 99.9999 pu 0.000
1
F004 0
" 36F8 Neutral Voltage Unbalance 1 Vop 0 to 99.9999 pu 0.000
1
F004 0
" 36FA Neutral Voltage Unbalance 1 Vrest 0 to 99.9999 pu 0.000
1
F004 0
" 36FC ...Repeated for Neutral Voltage Unbalance
2
" 3708 ...Repeated for Neutral Voltage Unbalance
3
Time of Day Timer Actuals (Read Only)
C70 3720 Seconds of Day 1 to 86400 --- 1 F003 0
" 3722 Day of Month 1 to 31 --- 1 F001 0
" 3723 Day of Year 1 to 366 --- 1 F001 0
" 3724 Year 1970 to 3000 --- 1 F001 0
Time of Day Timer Status Actual Values (Read Only)
C70 3730 Time of Day Timer 1 State 0 to 1 --- 1 F108 0 (Off)
Products Address Register name Range Units Step Format Default
