2-54 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 37A2 Frequency OOB Accumulator Band 3
Accumulation (OvUnFrecAccActualBand_3)
0.0 to 999.9 % 0.1 F001 0
" 37A3 Frequency OOB Accumulator Band 4
Accumulation (OvUnFrecAccActualBand_4)
0.0 to 999.9 % 0.1 F001 0
" 37A4 Frequency OOB Accumulator Band 5
Accumulation (OvUnFrecAccActualBand_5)
0.0 to 999.9 % 0.1 F001 0
" 37A5 Frequency OOB Accumulator Band 6
Accumulation (OvUnFrecAccActualBand_6)
0.0 to 999.9 % 0.1 F001 0
" 37A6 Frequency OOB Accumulator Band 7
Accumulation (OvUnFrecAccActualBand_7)
0.0 to 999.9 % 0.1 F001 0
Frequency Out-of-Band Accumulation Commands (Read/Write)
G30, G60 37A7 Reset Frequency Out-Of-Band
Accumulators
0 to 1 --- 1 F126 0 (No)
" 37A8 Preset Frequency Out-Of-Band
Accumulators
0 to 1 --- 1 F126 0 (No)
Phase Comparison Trip Scheme Actuals (Read Only)
L60 37B0 CT Bank1 Compensated I1 Current 0 to 999999.999 A 0.001 F060 0
" 37B2 CT Bank1 Compensated I2 Current 0 to 999999.999 A 0.001 F060 0
" 37B4 CT Bank2 Compensated I1 Current 0 to 999999.999 A 0.001 F060 0
" 37B6 CT Bank2 Compensated I2 Current 0 to 999999.999 A 0.001 F060 0
Field Units (Read/Write Setting) (8 Modules)
All except B90,
L60
3800 Field Unit 1 ID 0 to 1 --- 1 F205 "U1"
" 3806 Field Unit 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 3807 Field Unit 1 Type 0 to 3 --- 1 F243 0 (CC-05)
" 3808 Field Unit 1 Serial Number 1 to 1 --- 1 F205 "000000000
000"
" 380E Field Unit 1 Port 1 to 4 --- 1 F001 1
" 380F ...Repeated for Field Unit 2
" 381E ...Repeated for Field Unit 3
" 382D ...Repeated for Field Unit 4
" 383C ...Repeated for Field Unit 5
" 384B ...Repeated for Field Unit 6
" 385A ...Repeated for Field Unit 7
" 3869 ...Repeated for Field Unit 8
Field Unit Process Card Ports (Read/Write Setting)
All except B90,
L60
3878 Field Unit 1 Process Card Port 0 to 7 --- 1 F244 6 (H1a)
" 3879 Field Unit 2 Process Card Port 0 to 7 --- 1 F244 4 (H2a)
" 387A Field Unit 3 Process Card Port 0 to 7 --- 1 F244 2 (H3a)
" 387B Field Unit 4 Process Card Port 0 to 7 --- 1 F244 0 (H4a)
" 387C Field Unit 5 Process Card Port 0 to 7 --- 1 F244 7 (H1b)
" 387D Field Unit 6 Process Card Port 0 to 7 --- 1 F244 5 (H2b)
" 387E Field Unit 7 Process Card Port 0 to 7 --- 1 F244 3 (H3b)
" 387F Field Unit 8 Process Card Port 0 to 7 --- 1 F244 1 (H4b)
Field Unit CT VT Settings (Read/Write Setting) (6 Modules)
All except B90,
L60
3890 Remote Phase CT x Origin 1 0 to 16 --- 1 F247 0 (None)
" 3891 Remote Phase CT x Origin 2 0 to 16 --- 1 F247 0 (None)
" 3892 Remote Ground CT x Origin 1 0 to 16 --- 1 F248 0 (None)
Products Address Register name Range Units Step Format Default
