2-56 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 3A9A ...Repeated for Field Contact Input 23
" 3AA9 ...Repeated for Field Contact Input 24
" 3AB8 ...Repeated for Field Contact Input 25
" 3AC7 ...Repeated for Field Contact Input 26
" 3AD6 ...Repeated for Field Contact Input 27
" 3AE5 ...Repeated for Field Contact Input 28
" 3AF4 ...Repeated for Field Contact Input 29
" 3B03 ...Repeated for Field Contact Input 30
" 3B12 ...Repeated for Field Contact Input 31
" 3B21 ...Repeated for Field Contact Input 32
" 3B30 ...Repeated for Field Contact Input 33
" 3B3F ...Repeated for Field Contact Input 34
" 3B4E ...Repeated for Field Contact Input 35
" 3B5D ...Repeated for Field Contact Input 36
" 3B6C ...Repeated for Field Contact Input 37
" 3B7B ...Repeated for Field Contact Input 38
" 3B8A ...Repeated for Field Contact Input 39
" 3B99 ...Repeated for Field Contact Input 40
Field Unit Contact Outputs (Read/Write Setting) (8 Modules)
All except B90,
L60
3BA8 Field Contact Output 1 ID (6 items) --- --- --- F636 "FCO U /
OUT"
" 3BE4 Field Output 1 Operate (6 items) 0 to 4294967295 --- 1 F300 0
" 3BF0 Field Output 1 Seal In (6 items) 0 to 4294967295 --- 1 F300 0
" 3BFC Field Output 1 Events (6 items) 0 to 1 --- 1 F102 1 (Enabled)
" 3C02 ...Repeated for Field Contact Output 2
" 3C5C ...Repeated for Field Contact Output 3
" 3CB6 ...Repeated for Field Contact Output 4
" 3D10 ...Repeated for Field Contact Output 5
" 3D6A ...Repeated for Field Contact Output 6
" 3DC4 ...Repeated for Field Contact Output 7
" 3E1E ...Repeated for Field Contact Output 8
Field Unit Latching Outputs (Read/Write Setting) (8 Modules)
All except B90,
L60
3E78 Field Latching Output 1 ID 0 to 1 --- 1 F636 "FLO Ux /LO"
" 3E82 Field Latching Output 1 Open 0 to 4294967295 --- 1 F300 0
" 3E84 Field Latching Output 1 Close 0 to 4294967295 --- 1 F300 0
" 3E86 Field Latching Output 1 Events 0 to 1 --- 1 F102 1 (Enabled)
" 3E87 Field Latching Output 1 Reserved (2 items) 0 to 1 --- 1 F001 0
" 3E89 ...Repeated for Field Latching Output 2
" 3E9A ...Repeated for Field Latching Output 3
" 3EAB ...Repeated for Field Latching Output 4
" 3EBC ...Repeated for Field Latching Output 5
" 3ECD ...Repeated for Field Latching Output 6
" 3EDE ...Repeated for Field Latching Output 7
" 3EEF ...Repeated for Field Latching Output 8
Field Unit RTDs (Read/Write Setting) (8 Modules)
All except B90,
L60
3F00 Field Unit RTD 1 Name 0 to 1 --- 1 F205 "RTD 1"
