GE b30 Communications Guide

CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-57
2
" 3F06 Field Unit RTD 1 Origin 0 to 24 --- 1 F253 0 (None)
" 3F07 Field Unit RTD 1 Type 0 to 2 --- 1 F259 0 (100 Ohm
Nickel)
" 3F08 ...Repeated for Field Unit RTD 2
" 3F10 ...Repeated for Field Unit RTD 3
" 3F18 ...Repeated for Field Unit RTD 4
" 3F20 ...Repeated for Field Unit RTD 5
" 3F28 ...Repeated for Field Unit RTD 6
" 3F30 ...Repeated for Field Unit RTD 7
" 3F38 ...Repeated for Field Unit RTD 8
Field Unit Transducers (Read/Write Setting) (8 Modules)
All except B90,
L60
3F40 Field Unit Transducer 1 Name 0 to 1 --- 1 F205 "TRD 1"
" 3F46 Field Unit Transducer 1 Origin 0 to 24 --- 1 F253 0 (None)
" 3F47 Field Unit Transducer 1 Range 0 to 9 --- 1 F246 6 (0...20mA)
" 3F48 Field Unit Transducer 1 Min Value -9999.999 to
9999.999
--- 0.001 F004 0
" 3F4A Field Unit Transducer 1 Max Value -9999.999 to
9999.999
--- 0.001 F004 100000
" 3F4C Field Unit Transducer 1 Units --- --- --- F206 (none)
" 3F4F ...Repeated for Field Unit Transducer 2
" 3F5E ...Repeated for Field Unit Transducer 3
" 3F6D ...Repeated for Field Unit Transducer 4
" 3F7C ...Repeated for Field Unit Transducer 5
" 3F8B ...Repeated for Field Unit Transducer 6
" 3F9A ...Repeated for Field Unit Transducer 7
" 3FA9 ...Repeated for Field Unit Transducer 8
Field Unit Identifiers (Read Only) (8 Modules)
All except B90,
L60
3FB8 Attached Field Unit 1 Serial Number --- --- 1 F205 (none)
" 3FBE Attached Filed Unit 1 Port Number --- --- 1 F001 0
" 3FBF Attached Field Unit 1 Type 0 to 3 --- 1 F243 0 (CC-05)
" 3FC0 Field Unit 1 Status 0 to 4 --- 1 F262 0 (Disabled)
" 3FC1 ...Repeated for Field Unit 2
" 3FCA ...Repeated for Field Unit 3
" 3FD3 ...Repeated for Field Unit 4
" 3FDC ...Repeated for Field Unit 5
" 3FE5 ...Repeated for Field Unit 6
" 3FEE ...Repeated for Field Unit 7
" 3FF7 ...Repeated for Field Unit 8
Passwords (Read/Write Command)
All 4000 Command Password Setting 0 to 4294967295 --- 1 F202 (none)
Passwords (Read/Write Setting)
All 400A Setting Password Setting 0 to 4294967295 --- 1 F202 (none)
Passwords (Read/Write)
All 4014 Command Password Entry 0 to 4294967295 --- 1 F202 (none)
" 401E Setting Password Entry 0 to 4294967295 --- 1 F202 (none)
Products Address Register name Range Units Step Format Default
