CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-59
2
" 406C Charging Current Compensation 0 to 1 --- 1 F102 0 (Disabled)
" 406D Local Relay ID 0 to 255 --- 1 F001 0
" 406E Maximum Channel Asymmetry 0 to 10 ms 0.1 F001 15
" 406F Number of Channels 1 to 2 --- 1 F001 1
" 4070 Number of Terminals 2 to 3 --- 1 F001 2
" 4071 Positive Sequence Reactance 0.1 to 65.535 kohms 0.001 F001 100
" 4072 Round Trip Time 0 to 10 ms 0.1 F001 15
" 4073 Terminal 1 ID 0 to 255 --- 1 F001 0
" 4074 Terminal 2 ID 0 to 255 --- 1 F001 0
" 4075 Zero-Sequence Current Removal 0 to 1 --- 1 F102 0 (Disabled)
" 4076 Zero Sequence Reactance 0.1 to 65.535 kohms 0.001 F001 100
Remote RTD Communications (Read/Write Setting)
G60, M60, T60 407A RRTD Slave Address 1 to 254 --- 1 F001 254
" 407B RRTD Baud Rate 0 to 4 --- 1 F602 4 (19200)
Communications (Read/Write Setting)
All 407D COM2 Selection 0 to 3 --- 1 F601 0 (RS485)
" 407E COM1 Minimum Response Time 0 to 1000 ms 10 F001 0
" 407F COM2 Minimum Response Time 0 to 1000 ms 10 F001 0
" 4080 Modbus Slave Address 1 to 254 --- 1 F001 254
" 4083 RS485 Com1 Baud Rate 0 to 11 --- 1 F112 8 (115200)
" 4084 RS485 Com1 Parity 0 to 2 --- 1 F113 0 (None)
" 4085 RS485 Com2 Baud Rate 0 to 11 --- 1 F112 5 (19200)
" 4086 RS485 Com2 Parity 0 to 2 --- 1 F113 2 (Even)
" 4087 Port 1 IP Address 0 to 4294967295 --- 1 F003 2130706433
" 4089 Port 1 IP Subnet Mask 0 to 4294967295 --- 1 F003 4278190080
" 408B Port 1 Gateway IP Address 0 to 4294967295 --- 1 F003 56554497
" 408D Network Address NSAP --- --- --- F074 0
" 4097 Port 1 Link Loss Alert 0 to 1 --- 1 F102 0 (Disabled)
" 4098 Port 2 Link Loss Alert 0 to 1 --- 1 F102 0 (Disabled)
" 4099 Port 3 Link Loss Alert 0 to 1 --- 1 F102 0 (Disabled)
" 409A DNP Channel 1 Port 0 to 5 --- 1 F177 0 (NONE)
" 409B DNP Channel 2 Port 0 to 5 --- 1 F177 0 (NONE)
" 409C DNP Address 0 to 65519 --- 1 F001 1
" 409E DNP Client Addresses (2 items) 0 to 4294967295 --- 1 F003 0
" 40A3 TCP Port Number for the Modbus protocol 0 to 65535 --- 1 F001 502
" 40A4 TCP/UDP Port Number for the DNP Protocol 0 to 65535 --- 1 F001 20000
" 40A5 TCP Port Number for the HTTP (Web Server)
Protocol
0 to 65535 --- 1 F001 80
" 40A6 Main UDP Port Number for the TFTP
Protocol
0 to 65535 --- 1 F001 69
" 40A7 Data Transfer UDP Port Numbers for the
TFTP Protocol (zero means “automatic”) (2
items)
0 to 65535 --- 1 F001 0
" 40A9 DNP Unsolicited Responses Function 0 to 1 --- 1 F102 0 (Disabled)
" 40AA DNP Unsolicited Responses Timeout 0 to 60 s 1 F001 5
" 40AB DNP Unsolicited Responses Maximum
Retries
1 to 255 --- 1 F001 10
" 40AC DNP Unsolicited Responses Destination
Address
0 to 65519 --- 1 F001 1
