CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-77
2
Stub Bus (Read/Write Grouped Setting)
L30, L90 5F10 Stub Bus Function 0 to 1 --- 1 F102 0 (Disabled)
" 5F11 Stub Bus Disconnect 0 to 4294967295 --- 1 F300 0
" 5F13 Stub Bus Trigger 0 to 4294967295 --- 1 F300 0
" 5F15 Stub Bus Target 0 to 2 --- 1 F109 0 (Self-reset)
" 5F17 Stub Bus Events 0 to 1 --- 1 F102 0 (Disabled)
50DD Disturbance Detection (Read/Write Grouped Setting)
L30, L90 5F20 50DD Function 0 to 1 --- 1 F102 0 (Disabled)
" 5F21 50DD Non Current Supervision 0 to 4294967295 --- 1 F300 0
" 5F23 50DD Control Logic 0 to 4294967295 --- 1 F300 0
" 5F25 50DD Logic Seal In 0 to 4294967295 --- 1 F300 0
" 5F27 50DD Events 0 to 1 --- 1 F102 0 (Disabled)
" 5F28 50DD Seal-In by 87LG 0 to 1 --- 1 F102 0 (Disabled)
" 5F29 50DD Voltage Supv 0 to 1 --- 1 F102 0 (Disabled)
Frequency Out-Of-Band Accumulation (Read/Write Setting)
G30, G60 5F40 Frequency Out-Of-Band Accumulation
Block
0 to 4294967295 --- 1 F300 0
" 5F42 Frequency Out-Of-Band Accumulation
Events Enable
0 to 1 --- 1 F102 0 (Disabled)
" 5F43 Frequency Out-Of-Band Accumulator
Function Enable Array (7 items)
0 to 1 --- 1 F102 0 (Disabled)
" 5F4A Frequency Out-Of-Band Accumulator
Lower Frequency Array (7 items)
20 to 70 Hz 0.01 F001 6000
" 5F51 Frequency Out-Of-Band Accumulator Min
Value V A
0.1 to 1.25 pu 0.01 F001 10
" 5F52 Frequency Out-Of-Band Accumulator
Source
0 to 5 --- 1 F167 0 (SRC 1)
" 5F53 Frequency Out-Of-Band Accumulator
Target Messages Enable
0 to 2 --- 1 F109 0 (Self-reset)
" 5F54 Frequency Out-Of-Band Accumulator Time
Limit Array (7 items)
1 to 65535 sec 1 F001 200
" 5F5B Frequency Out-Of-Band Accumulator Time
Preset Array (7 items)
0 to 65535 sec 1 F001 0
" 5F62 Frequency Out-Of-Band Accumulator
Upper Frequency Array (7 items)
20 to 70 Hz 0.01 F001 6000
Setting Groups (Read/Write Setting)
All except C30 5F70 Setting Group for Modbus Comms (0
means group 1)
0 to 5 --- 1 F001 0
" 5F71 Setting Groups Block 0 to 4294967295 --- 1 F300 0
" 5F73 FlexLogic Operands to Activate Groups 2
through 6 (5 items)
0 to 4294967295 --- 1 F300 0
" 5F7D Setting Group Function 0 to 1 --- 1 F102 0 (Disabled)
" 5F7E Setting Group Events 0 to 1 --- 1 F102 0 (Disabled)
Setting Groups (Read Only)
All except C30 5F7F Current Setting Group 0 to 5 --- 1 F001 0
Setting Group Names (Read/Write Setting)
All except C30 5F8C Setting Group 1 Name --- --- --- F203 (none)
" 5F94 Setting Group 2 Name --- --- --- F203 (none)
" 5F9C Setting Group 3 Name --- --- --- F203 (none)
" 5FA4 Setting Group 4 Name --- --- --- F203 (none)
" 5FAC Setting Group 5 Name --- --- --- F203 (none)
Products Address Register name Range Units Step Format Default
