2-78 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 5FB4 Setting Group 6 Name --- --- --- F203 (none)
Current Differential 87L (Read/Write Grouped Setting)
L30, L90 6000 87L Current Differential Function 0 to 1 --- 1 F102 0 (Disabled)
" 6001 87L Current Differential Block 0 to 4294967295 --- 1 F300 0
" 6003 87L Current Differential Signal Source 1 0 to 5 --- 1 F167 0 (SRC 1)
" 6004 87L Minimum Phase Current Sensitivity 0.1 to 4 pu 0.01 F001 20
" 6005 87L Current Differential Tap Setting 0.2 to 5 --- 0.01 F001 100
" 6006 87L Current Differential Phase Percent
Restraint 1
1 to 50 % 1 F001 30
" 6007 87L Current Differential Phase Percent
Restraint 2
1 to 70 % 1 F001 50
" 6008 87L Current Differential Phase Dual Slope
Breakpoint
0 to 20 pu 0.1 F001 10
" 6009 87L Current Differential Ground Function 0 to 1 --- 1 F102 0 (Disabled)
" 600A 87L Current Differential Ground Pickup 0.05 to 1 pu 0.01 F001 10
" 600B 87L Current Differential Ground Restraint 1 to 50 % 1 F001 25
" 600C 87L Current Differential Ground Delay 0 to 5 seconds 0.01 F001 10
" 600D 87L Current Differential Key DTT 0 to 1 --- 1 F102 1 (Enabled)
" 600E 87L Current Differential External Key DTT 0 to 4294967295 --- 1 F300 0
" 6010 87L Current Differential Target 0 to 2 --- 1 F109 0 (Self-reset)
" 6011 87L Current Differential Event 0 to 1 --- 1 F102 0 (Disabled)
" 6012 87L Current Differential Tap 2 Setting 0.2 to 5 --- 0.01 F001 100
L90 6013 87L Current Differential Signal Source 2 0 to 6 --- 1 F211 0 (None)
" 6014 87L Current Differential Signal Source 3 0 to 6 --- 1 F211 0 (None)
" 6015 87L Current Differential Signal Source 4 0 to 6 --- 1 F211 0 (None)
Current Differential 87L In-Zone Transformer (Read/Write Grouped Setting)
L30, L90 601E 87L Inrush Inhibit Mode 0 to 3 --- 1 F561 0 (Disabled)
" 601F 87L Inrush Inhibit Level 1 to 40 %fo 0.1 F001 200
Open Pole Detect (Read/Write Grouped Setting)
N60 6040 Open Pole Detect Function 0 to 1 --- 1 F102 0 (Disabled)
" 6041 Open Pole Detect Block 0 to 4294967295 --- 1 F300 0
" 6043 Open Pole Detect A Aux Co 0 to 4294967295 --- 1 F300 0
" 6045 Open Pole Detect B Aux Co 0 to 4294967295 --- 1 F300 0
" 6047 Open Pole Detect C Aux Co 0 to 4294967295 --- 1 F300 0
" 6049 Open Pole Detect Current Source 0 to 5 --- 1 F167 0 (SRC 1)
" 604A Open Pole Detect Current Pickup 0.05 to 20 pu 0.01 F001 20
" 604B Open Pole Detect Voltage Source 0 to 5 --- 1 F167 0 (SRC 1)
" 604C Open Pole Detect Voltage Input 0 to 1 --- 1 F102 0 (Disabled)
" 604D Open Pole Detect Pickup Delay 0 to 65.535 s 0.001 F001 60
" 604E Open Pole Detect Reset Delay 0 to 65.535 s 0.001 F001 100
" 604F Open Pole Detect Target 0 to 2 --- 1 F109 0 (Self-reset)
" 6050 Open Pole Detect Events 0 to 1 --- 1 F102 0 (Disabled)
" 6051 Open Pole Detect Broken Co 0 to 1 --- 1 F102 0 (Disabled)
Phase Comparison Negative Sequence Voltage (Read/Write Grouped Setting)
L60 6070 Negative Sequence Voltage FD Function 0 to 1 --- 1 F102 0 (Disabled)
" 6071 Negative Sequence Voltage FD Impedance 0 to 100 % 0.1 F001 100
" 6072 Negative Sequence Voltage FDL Pickup 0.005 to 3 pu 0.001 F001 10
" 6073 Negative Sequence Voltage FDH Pickup 0.005 to 3 pu 0.001 F001 50
