GE b30 Communications Guide

CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-79
2
" 6074 Negative Sequence Voltage FD Block 0 to 4294967295 --- 1 F300 0
" 6076 Negative Sequence Voltage FD Target 0 to 2 --- 1 F109 0 (Self-reset)
" 6077 Negative Sequence Voltage FD Events 0 to 1 --- 1 F102 0 (Disabled)
Phase Comparison Negative Sequence Current Rate of Change (ROC) (Read/Write Grouped Setting)
L60 6080 Negative Sequence di/dt FD Function 0 to 1 --- 1 F102 0 (Disabled)
" 6081 Negative Sequence di/dt FDL Pickup 0.01 to 5 pu 0.01 F001 10
" 6082 Negative Sequence di/dt FDL Seal-In 0 to 10 s 0.001 F001 600
" 6083 Negative Sequence di/dt FDH Pickup 0.01 to 5 pu 0.01 F001 50
" 6084 Negative Sequence di/dt FDH Seal-In 0 to 10 s 0.001 F001 200
" 6085 Negative Sequence di/dt FDH Supv 0 to 4294967295 --- 1 F300 0
" 6087 Negative Sequence di/dt FD Block 0 to 4294967295 --- 1 F300 0
" 6089 Negative Sequence di/dt FD Target 0 to 2 --- 1 F109 0 (Self-reset)
" 608A Negative Sequence di/dt FD Events 0 to 1 --- 1 F102 0 (Disabled)
Phase Comparison Rate of Change of Positive-Sequence Current Settings (Read/Write Grouped Setting)
L60 6092 Positive-sequence Current Rate of Change
(di/dt FD) Function
0 to 1 --- 1 F102 0 (Disabled)
" 6093 Positive-sequence Current Rate of Change
(di/dt FDL) Low Pickup
0.01 to 5 pu 0.01 F001 10
" 6094 Positive-sequence Current Rate of Change
(di/dt FDL) Low Seal-in
0 to 10 s 0.001 F001 600
" 6095 Positive-sequence Current Rate of Change
(di/dt FDH) High Pickup
0.01 to 5 pu 0.01 F001 50
" 6096 Positive-sequence Current Rate of Change
(di/dt FDH) High Seal-in
0 to 10 s 0.001 F001 200
" 6097 Positive-sequence Current Rate of Change
(di/dt FDH) Supervision
0 to 4294967295 --- 1 F300 0
" 6099 Positive-sequence Current Rate of Change
(di/dt FD) Block
0 to 4294967295 --- 1 F300 0
" 609B Positive-sequence Current Rate of Change
(di/dt FD) Events
0 to 1 --- 1 F102 0 (Disabled)
" 609C Positive-sequence Current Rate of Change
(di/dt FD) Target
0 to 2 --- 1 F109 0 (Self-reset)
Phase Comparison Negative-Sequence Current Fault Detector (Read/Write Grouped Settings)
L60 60A0 Negative-sequence Current Fault Detector
Function
0 to 1 --- 1 F102 0 (Disabled)
" 60A1 Negative-sequence Current Fault Detector
Low Pickup
0.02 to 5 pu 0.01 F001 10
" 60A2 Negative-sequence Current Fault Detector
High Pickup
0.05 to 15 pu 0.01 F001 50
" 60A3 Negative-sequence Current Fault Detector
Block
0 to 4294967295 --- 1 F300 0
" 60A5 Negative-sequence Current Fault Detector
Target
0 to 2 --- 1 F109 0 (Self-reset)
" 60A6 Negative-sequence Current Fault Detector
Events
0 to 1 --- 1 F102 0 (Disabled)
Phase Comparison Positive-Sequence Current Fault Detector (Read/Write Grouped Settings)
L60 60A8 Positive-sequence Current Fault Detector
Function
0 to 1 --- 1 F102 0 (Disabled)
" 60A9 Positive-sequence Current Fault Detector
Low Pickup
0.2 to 5 pu 0.01 F001 50
" 60AA Positive-sequence Current Fault Detector
High Pickup
0.5 to 15 pu 0.01 F001 75
Products Address Register name Range Units Step Format Default
