7. Air Filter & Air Intake Vents –
For proper cooling it is
important to keep the air filter
clean and clear of obstructions.
See the maintenance section of
this manual for more details.
8. AC Power Cord Receptacle – Is
where the AC power cord plugs
in.
9. Mounting Bracket Holes – Four
M4 threaded holes on the
bottom of the main unit are
used to attach the optional
mounting bracket. The
mounting bracket can be
positioned on the left or right
side of the light box.
