9
Turn off Power and Remove the Fluidics Cover
Maintenance - Replacing Pump Head
1
Turn off power.
Remove the fluidics cover.
断开进出水管,按图旋下两颗螺
丝,取下CheckPoint右侧外壳。
Enlever le cache fluidique.
Die Abdeckung der
Flüssigkeitsleitungen entfernen.
Rimuovere il portello della
fluidica.
フルイディクス カバーを外し
ます。
Quite la cubierta fluídica.
