GE Corometrics 171 - Strip Chart Recorder

Revision D 170 Series Monitor 7-1
2003023-001
Chapter 7
Strip Chart Recorder 7
This chapter discusses the different types of strip chart paper as well as the trends
and annotations which are printed.
This section includes the following information:
Strip Chart Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Trends. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Annotations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Paper Error Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Removing Unused Paper from the Recorder . . . . . . . . . . . . . . . . . . 7-13
