GE Multilin D60 Line Distance Protection System 2-13
2 PRODUCT DESCRIPTION 2.2 ORDER CODES
2
The order codes for the reduced size vertical mount units with the process bus module are shown below.
7T RS422, 1 Channel
7W RS422, 2 Channels
Table 2–7: D60 ORDER CODES FOR REDUCED SIZE VERTICAL UNITS WITH PROCESS BUS (SHEET 1 OF 2)
D60 - * ** - * * * - F ** - H ** - M ** - P/R ** Reduced Size Vertical Mount (see note regarding P/R slot below)
BASE UNIT D60 | | | | | | | | | Base Unit
CPU T | | | | | | | | RS485 and Three Multi-mode fiber 100Base-FX (SFP with LC)
U | | | | | | | | RS485 and Two Multi-mode fiber 100Base-FX (SFP with LC), One 10/100Base-T (SFP with RJ45)
V | | | | | | | | RS485 and Three 10/100Base-T (SFP with RJ45)
SOFTWARE 00 | | | | | | | No software options
03 | | | | | | | IEC 61850 communications
06 | | | | | | | Phasor measurement unit (PMU)
07 | | | | | | | IEC 61850 communications and phasor measurement unit (PMU)
A0 | | | | | | | CyberSentry Lvl 1
A2 | | | | | | | CyberSentry Lvl 1 and Breaker-and-a-half
A3 | | | | | | | CyberSentry Lvl 1 and IEC 61850
A5 | | | | | | | CyberSentry Lvl 1 and IEC 61850 and Breaker-and-a-half
A6 | | | | | | | CyberSentry Lvl 1 and phasor measurement unit (PMU)
A7 | | | | | | | CyberSentry Lvl 1 and IEC 61850 and phasor measurement unit (PMU)
A8 | | | | | | | CyberSentry Lvl 1 and phasor measurement unit (PMU) and Breaker-and-a-half
A9 | | | | | | | CyberSentry Lvl 1 and IEC 61850 and phasor measurement unit (PMU) and Breaker-and-a-half
B0 | | | | | | | IEEE 1588
B2 | | | | | | | IEEE 1588 and Breaker-and-a-half
B3 | | | | | | | IEEE 1588 and IEC 61850
B5 | | | | | | | IEEE 1588 and IEC 61850 and Breaker-and-a-half
B6 | | | | | | | IEEE 1588 and phasor measurement unit (PMU)
B7 | | | | | | | IEEE 1588 and IEC 61850 and phasor measurement unit (PMU)
B8 | | | | | | | IEEE 1588 and phasor measurement unit (PMU) and Breaker-and-a-half
B9 | | | | | | | IEEE 1588 and IEC 61850 and phasor measurement unit (PMU) and Breaker-and-a-half
C0 | | | | | | | Parallel Redundancy Protocol (PRP)
C2 | | | | | | | PRP and Breaker-and-a-half
C3 | | | | | | | PRP and IEC 61850
C5 | | | | | | | PRP, IEC 61850, and Breaker-and-a-half
C6 | | | | | | | PRP and PMU
C7 | | | | | | | PRP, IEC 61850, and PMU
C8 | | | | | | | PRP, Breaker-and-a-half, and PMU
C9 | | | | | | | PRP, IEC 61850, Breaker-and-a-half, and PMU
D0 | | | | | | | IEEE 1588 and CyberSentry Lvl 1
D2 | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850
D3 | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850
D5 | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850
D6 | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and phasor measurement unit (PMU)
D7 | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and phasor measurement unit (PMU)
D8 | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and phasor measurement unit (PMU)
D9 | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 + phasor measurement unit (PMU) + Breaker-and-a-half
E0 | | | | | | | IEEE 1588 and PRP
E2 | | | | | | | IEEE 1588, PRP, and Breaker-and-a-half
E3 | | | | | | | IEEE 1588, PRP, and IEC 61850
E5 | | | | | | | IEEE 1588, PRP, IEC 61850, and Breaker-and-a-half
E6 | | | | | | | IEEE 1588, PRP, and PMU
E7 | | | | | | | IEEE 1588, PRP, IEC 61850, and PMU
E8 | | | | | | | IEEE 1588, PRP, Breaker-and-a-half, and PMU
E9 | | | | | | | IEEE 1588, PRP, IEC 61850, Breaker-and-a-half, and PMU
F0 | | | | | | | PRP and CyberSentry Lvl 1
F2 | | | | | | | PRP, CyberSentry Lvl 1, and Breaker-and-a-half
F3 | | | | | | | PRP, CyberSentry Lvl 1, and IEC 61850
F5 | | | | | | | PRP CyberSentry Lvl 1, IEC 61850, and Breaker-and-a-half
F6 | | | | | | | PRP, CyberSentry Lvl 1, and PMU
F7 | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, and PMU
F8 | | | | | | | PRP, CyberSentry Lvl 1, Breaker-and-a-half, and PMU
F9 | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, Breaker-and-a-half, and PMU
G0 | | | | | | | IEEE 1588, PRP, and CyberSentry Lvl 1
G2 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Breaker-and-a-half
G3 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
G5 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and Breaker-and-a-half
G6 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and PMU
G7 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and PMU
G8 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Breaker-and-a-half, and PMU
G9 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, Breaker-and-a-half, and PMU
J0 | | | | | | | IEC 60870-5-103
J2 | | | | | | | IEC 60870-5-103 + Breaker-and-a-half
J3 | | | | | | | IEC 60870-5-103 + IEC 61850
J5 | | | | | | | IEC 60870-5-103 + IEC 61850 + Breaker-and-a-half
J6 | | | | | | | IEC 60870-5-103 + PMU
J7 | | | | | | | IEC 60870-5-103 + IEC 61850 + PMU
J8 | | | | | | | IEC 60870-5-103 + Breaker-and-a-half + PMU
J9 | | | | | | | IEC 60870-5-103 + IEC 61850 + Breaker-and-a-half + PMU
K0 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103
K2 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + Breaker-and-a-half
K3 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + IEC 61850
K5 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + IEC 61850 + Breaker-and-a-half
K6 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + PMU
K7 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + IEC 61850 + PMUI
K8 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + Breaker-and-a-half + PMU
K9 | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + IEC 61850 + Breaker-and-a-half + PMU
L0 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1
L2 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + Breaker-and-a-half
L3 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850
L5 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850 + Breaker-and-a-half
L6 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + PMU
L7 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850 + PMU
L8 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + Breaker-and-a-half + PMU
L9 | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1+ IEC 61850 + Breaker-and-a-half + PMU
MOUNT/COATING V | | | | | | Vertical (3/4 rack)
B | | | | | | Vertical (3/4 rack) with harsh environmental coating
FACEPLATE/ DISPLAY F | | | | | English display
D | | | | | French display
R | | | | | Russian display
A | | | | | Chinese display
K | | | | | Enhanced front panel with English display
M | | | | | Enhanced front panel with French display
Q | | | | | Enhanced front panel with Russian display
U | | | | | Enhanced front panel with Chinese display
L | | | | | Enhanced front panel with English display and user-programmable pushbuttons
N | | | | | Enhanced front panel with French display and user-programmable pushbuttons
T | | | | | Enhanced front panel with Russian display and user-programmable pushbuttons
V | | | | | Enhanced front panel with Chinese display and user-programmable pushbuttons
W | | | | | Enhanced front panel with Turkish display
Y | | | | | Enhanced front panel with Turkish display and user-programmable pushbuttons
I | | | | | Enhanced front panel with German display
J | | | | | Enhanced front panel with German display and user-programmable pushbuttons
Table 2–6: D60 ORDER CODES FOR HORIZONTAL UNITS WITH PROCESS BUS (SHEET 3 OF 3)
D60 - * ** - * * * - F ** - H ** - M ** - P ** - U ** - W/X ** Full Size Horizontal Mount
BASE UNIT D60 | | | | | | | | | | | Base Unit
