6-24 D60 Line Distance Protection System GE Multilin
6.3 METERING 6 ACTUAL VALUES
6
6.3.13 DISTANCE
PATH: ACTUAL VALUES  METERING  DISTANCE
 DISTANCE

AB LOOP RESISTANCE
RAB: 0.00 Ohms
MESSAGE
AB LOOP REACTANCE
XAB: 0.00 Ohms
MESSAGE
AB LOOP IMPEDANCE
ZAB: 0.00 Ohms
MESSAGE
AB LOOP IMPEDANCE
ANGLE: 0.00 DEG
MESSAGE
BC LOOP RESISTANCE
RBC: 0.00 Ohms
MESSAGE
BC LOOP REACTANCE
XBC: 0.00 Ohms
MESSAGE
BC LOOP IMPEDANCE
ZBC: 0.00 Ohms
MESSAGE
BC LOOP IMPEDANCE
ANGLE: 0.00 DEG
MESSAGE
CA LOOP RESISTANCE
RCA: 0.00 Ohms
MESSAGE
CA LOOP REACTANCE
XCA: 0.00 Ohms
MESSAGE
CA LOOP IMPEDANCE
ZCA: 0.00 Ohms
MESSAGE
CA LOOP IMPEDANCE
ANGLE: 0.00 DEG
MESSAGE
AG LOOP RESISTANCE
RAG: 0.00 Ohms
MESSAGE
AG LOOP REACTANCE
XAG: 0.00 Ohms
MESSAGE
AG LOOP IMPEDANCE
ZAG: 0.00 Ohms
MESSAGE
AG LOOP IMPEDANCE
ANGLE: 0.00 DEG
MESSAGE
BG LOOP RESISTANCE
RBG: 0.00 Ohms
MESSAGE
BG LOOP REACTANCE
XBG: 0.00 Ohms
MESSAGE
BG LOOP IMPEDANCE
ZBG: 0.00 Ohms
MESSAGE
BG LOOP IMPEDANCE
ANGLE: 0.00 DEG
MESSAGE
CG LOOP RESISTANCE
RCG: 0.00 Ohms
