GE Multilin D60 Line Distance Protection System 5-331
5 SETTINGS 5.7 CONTROL ELEMENTS
5
f) HYBRID PERMISSIVE OVER-REACHING TRANSFER TRIP
PATH: SETTINGS  CONTROL ELEMENTS  PILOT SCHEMES  HYBRID POTT SCHEME
 HYBRID POTT SCHEME

HYB POTT SCHEME
FUNCTION: Disabled
Range: Disabled, Enabled
MESSAGE
HYB POTT BLOCK:
Off
Range: FlexLogic operand
MESSAGE
HYB POTT PERMISSIVE
ECHO: Disabled
Range: Disabled, Enabled, Custom
MESSAGE
HYB POTT ECHO COND:
Off
Range: FlexLogic operand
MESSAGE
HYB POTT WEAK
INFEED: Enabled
Range: Disabled, Enabled, Custom
MESSAGE
HYB POTT W/I COND:
Off
Range: FlexLogic operand
MESSAGE
HYB POTT RX PICKUP
DELAY: 0.000 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
TRANS BLOCK PICKUP
DELAY: 0.020 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
TRANS BLOCK RESET
DELAY: 0.090 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
ECHO DURATION:
0.100 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
ECHO LOCKOUT:
0.250 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
HYB POTT SEAL-IN
DELAY: 0.010 s
Range: 0.000 to 65.535 s in steps of 0.001
MESSAGE
GND DIR O/C FWD:
Off
Range: FlexLogic operand
MESSAGE
GND DIR O/C REV:
Off
Range: FlexLogic operand
MESSAGE
HYB POTT NO OF COMM
BITS: 1
Range: 1, 2, or 4
MESSAGE
HYB POTT RX1:
Off
Range: FlexLogic operand
MESSAGE
HYB POTT RX2:
Off
Range: FlexLogic operand
MESSAGE
HYB POTT RX3:
Off
Range: FlexLogic operand
MESSAGE
HYB POTT RX4:
Off
Range: FlexLogic operand
MESSAGE
HYB POTT SCHEME
TARGET: Self-Reset
Range: Self-Reset, Latched, Disabled
MESSAGE
HYB POTT EVENT:
Disabled
Range: Disabled, Enabled
